Захранване MSI MAG A750BN PCIE5 II

80 Plus Bronze Certified:
The efficiency of your power supply directly influences your system’s performance and your power consumption. The 80 Plus Bronze certification promises lower energy consumption and higher efficiency.

ATX 3.1 Ready:
It has an output port that is compliant with PCIe CEM 5.1 and Intel PSDG (Power Supply Design Guide)ATX 3.1, also this power supply can hold up to 2x total power excursion and 3x GPU power excursion.

PCIe CEM 5.1 ready:
This power supply features a native PCIe 12V-2x6 connector with a 450W power capacity, compliant with the PCIe CEM 5.1 standard, providing more stable and secure power delivery for graphics cards.

Specifications

Efficiency Rating
80 PLUS Bronze (up to 85%)

Modular
No

Fan Size
120 mm

Fan Bearing
Hydrualic Bearing

Dimensions (DxWxH)
140mm x 150mm x 86mm / 5.51 x 5.9 x 3.38 inches

PFC Type
Active PFC

Input Voltage Range
100-240V~

Power Watt
750W

Power Excursion
200%

Input Frequency Range
50-60Hz

Protection
OVP, OCP, SCP, OPP, UVP

ATX (24 pin)
1

EPS (8 pin)
1

EPS (4+4 pin)
1

PCI-E 5.1 (16 pin)
1 (450W)

PCI-E (6+2 pin)
3

SATA (15 pin)
3

Peripheral (4 pin)
2
