FSP
Захранване FSP Group (FFSP180-50FEB)
Артикул №: 1000127413
Категория:
Компютърни компоненти
51,99 €
✓ Ограничена наличност
FSP FFSP180-50FEB
FSP180-50FEB is a standard Flex form factor switching power supply. The power supply comes to offer the total power capacity up to 180 Watts, which makes it to be ideally used in an industrial environment. In addition, the power supply is ideally the best choice for IPC controller, networking, communication or any other automation applications to use. The product also complies with the latest safety and EMC standards, which is perfectly to meet various regulations worldwide.
- Certified CB 62368-1 & CB 60950-1
- Meet 80 Plus Bronze
- Design for 5,000 Meters above sea level
- High Reliability
- Low Ripple & Noise
- Over Current Protection
- Over Temperature Protection
- Over Voltage Protection
Характеристики
| Working temperature | 0°C to 50°C |
| Температура на съхранение | -20°C to + 80°C |
| Efficiency | 80 Plus Bronze Working humidity: 85% RH non-condensing |
| Storage humidity | 95% RH non-condensing |
| Hold-up time at 100% 115V / 60Hz | ≥ 16ms |
| Loading | 230V / 50Hz: ≥ 16ms MTBF: 100,000 hours of continuous operation at 25°C, Max,-output load |
| Operating altitude | 5,000 meters above sea level Applications: Networking ,Storage System ,IPC Controller |
| Outputs +3.3V +5V +12V -12V +5Vsb | Да |
| Max. | 8.0A 12.0A 12.0A 0.3A 2.0A |
| Min. | 0.0A 0.0A 0.05A 0.0A 0.0A |
| Regulation ±5% ±5% ±5% ±10% ±5% | Да |
| Ripple/Noise | 50 mV 50 mV 120 mV 120 mV 50 mV |
