Захранване Chieftec Task TPS-500S

Chieftec TPS-500S, 500W retail

Performance
Model: Task 500W
Article no.: TPS-500S
EAN code: 0753263076489
Weight (without/with package) 1.62 kg / 2.03 kg
AC Input: 100-240V / 8.0A
Frequency: 47-63Hz
+5V: 16A
+3,3V: 18A
+5V & +3,3V combined: 100W
+12V 1: 456W / 38A
+12V 2: -
+12V 1 & +12V 2 combined: -
P.F.: >0,9
-12V: 0,3A / 3,6W
+5VsB: 2,5A / 12,5W
Maximum Power 500W

Connectors
24PIN ATX: 1
8 PIN EPS (4+4): 1
8 PIN PCIe (6+2): 1
SATA: 5
MOLEX: 3

Cable length
24PIN ATX: 650
8 PIN EPS (4+4): 650
8 PIN PCIe (6+2): 500
SATA/MOLEX/MOLEX: 500/150/150
MOLEX/SATA/SATA: 500/150/150
SATA: 500/150

Features
Specification: ATX 12V 2.3
Form factor: PS II
Efficiency: 80 PLUS® Bronze
Dimension (DxWxH): 140 mm x 150 mm x 87 mm
PFC: Active PFC (0.9)
Fan: 120mm silent fan

Security
AFC (Automatic Fanspeed Control)
OPP (Overload Protection)
OTP (Over Temperature Protection)
OVP (Overvoltage Protection)
SCP (Short Circuit Protection)
SIP (Surge & Inrush Protection)
UVP (Undervoltage Protection)

JAR Computers може да предложи /смяна/монтаж в наш сервиз или при .
