Захранване A-Data XPG PROBE
PROBE
VIABLE, APPLIABLE, & RELIABLE
With up to 87% efficiency at 50% load and a 120mm low-noise fan featuring an intelligent curve, XPG PROBE is designed to deliver stable and reliable power to your system!
Enhanced Safety in Operation:
Unlike most Bronze power supply units, XPG PROBE is ATX v2.52 compliant, enhancing overall reliability and providing safer operation for your current and future hardware.
Intelligent Fan-Curve Design:
The 120mm low-noise sleeve-bearing fan, featuring an intelligent curve design, keeps the power supply cool without excessive noise, thus reducing power consumption for cooling and improving overall energy efficiency.
Long, Reliable Lifespan:
XPG PROBE comes with premium capacitors with a 105°C rating, offering greater reliability, premium efficiency, and a longer lifespan.
Характеристики
| X 150 x 86mm | 140 |
| Plus Rating | 80 |
| BRONZE | Да |
| ATX Version | Да |
| ATX | 2.52 |
| Protections | Да |
| OVP / OPP / SCP / UVP / OTP / SIP | Да |
| Сертификация | Да |
| PFC | Да |
| 0.99 @ Typical load | Да |
| Input Voltage | Да |
| 100-240V, 47~63Hz | Да |
| Input Current | Да |
| 9A - 10A | Да |
| Input Frequency | Да |
| 47 - 63Hz | Да |
| DC Output Voltage | Да |
| 5V | +3.3V | +12V | -12V | +5Vsb | Да |
| Total Output | Да |
| 700W | +5V: 17A, +3.3V:19A, +12V:54A, -12V:0.3A, +5Vsb:2.5A 600W: +5V: 17A, +3.3V:19A, +12V:46A, -12V:0.3A, +5Vsb:2.5A |
| Power Excursion | Да |
| Total | 700W +5V/+3.3V:110W, +12V:648W, -12V:3.6W, +5Vsb:12.5W Total:600W +5V/+3.3V:110W, +12V:552W, -12V:3.6W, +5Vsb:12.5W |
| Работна температура | Да |
| 0~40°C | Да |
| Fan Size | Да |
| 120mm | Да |
| Fan Bearing | Да |
| Sleeve Bearing Fan | Да |
| Fan Speed | Да |
| 2400 ± 10% RPM | Да |
| MTBF | Да |
| Hours @ 25°C | 100,000 |
| ATX | 24 Pin Connector |
| 1 | Да |
| EPS | 8 (4+4) Pin Connector |
| 2 | Да |
| Molex | 4 Pin Connector |
| 2 | Да |
| SATA Connector | Да |
| 5 | Да |
