A-Data
Захранване A-Data XPG PROBE
Артикул №: 1000041616
Категория:
Захранвания Настолни компютри
50,99 €
✓ Налично във външен склад
PROBE
VIABLE, APPLIABLE, & RELIABLE
With up to 87% efficiency at 50% load and a 120mm low-noise fan featuring an intelligent curve, XPG PROBE is designed to deliver stable and reliable power to your system!
Enhanced Safety in Operation:
Unlike most Bronze power supply units, XPG PROBE is ATX v2.52 compliant, enhancing overall reliability and providing safer operation for your current and future hardware.
Intelligent Fan-Curve Design:
The 120mm low-noise sleeve-bearing fan, featuring an intelligent curve design, keeps the power supply cool without excessive noise, thus reducing power consumption for cooling and improving overall energy efficiency.
Long, Reliable Lifespan:
XPG PROBE comes with premium capacitors with a 105°C rating, offering greater reliability, premium efficiency, and a longer lifespan.
Specifications
Dimensions (L x W x H)
140 x 150 x 86mm
80 Plus Rating
BRONZE
ATX Version
ATX 2.52
Protections
OVP / OPP / SCP / UVP / OTP / SIP
Certification
CB, CE, FCC, TUV, cTUVus, BSMI, CCC, NOM, FCC IC, UKCA,EAC, RCM
PFC
> 0.99 @ Typical load
Input Voltage
100-240V, 47~63Hz
Input Current
9A - 10A
Input Frequency
47 - 63Hz
DC Output Voltage
+5V | +3.3V | +12V | -12V | +5Vsb
Total Output
VIABLE, APPLIABLE, & RELIABLE
With up to 87% efficiency at 50% load and a 120mm low-noise fan featuring an intelligent curve, XPG PROBE is designed to deliver stable and reliable power to your system!
Enhanced Safety in Operation:
Unlike most Bronze power supply units, XPG PROBE is ATX v2.52 compliant, enhancing overall reliability and providing safer operation for your current and future hardware.
Intelligent Fan-Curve Design:
The 120mm low-noise sleeve-bearing fan, featuring an intelligent curve design, keeps the power supply cool without excessive noise, thus reducing power consumption for cooling and improving overall energy efficiency.
Long, Reliable Lifespan:
XPG PROBE comes with premium capacitors with a 105°C rating, offering greater reliability, premium efficiency, and a longer lifespan.
Specifications
Dimensions (L x W x H)
140 x 150 x 86mm
80 Plus Rating
BRONZE
ATX Version
ATX 2.52
Protections
OVP / OPP / SCP / UVP / OTP / SIP
Certification
CB, CE, FCC, TUV, cTUVus, BSMI, CCC, NOM, FCC IC, UKCA,EAC, RCM
PFC
> 0.99 @ Typical load
Input Voltage
100-240V, 47~63Hz
Input Current
9A - 10A
Input Frequency
47 - 63Hz
DC Output Voltage
+5V | +3.3V | +12V | -12V | +5Vsb
Total Output
Характеристики
| X 150 x 86mm | 140 |
| Plus Rating | 80 |
| ATX | 2.52 |
| 700W | +5V: 17A, +3.3V:19A, +12V:54A, -12V:0.3A, +5Vsb:2.5A 600W: +5V: 17A, +3.3V:19A, +12V:46A, -12V:0.3A, +5Vsb:2.5A |
| Total | 700W +5V/+3.3V:110W, +12V:648W, -12V:3.6W, +5Vsb:12.5W Total:600W +5V/+3.3V:110W, +12V:552W, -12V:3.6W, +5Vsb:12.5W |
| Hours @ 25°C | 100,000 |
| ATX | 24 Pin Connector |
| EPS | 8 (4+4) Pin Connector |
| Molex | 4 Pin Connector |
