Видео карта AMD Radeon RX 9070 XT
GPU
AMD Radeon RX 9070 XT Graphics Card
AMD RDNA 4 Architecture
Engine Clock
- Boost Clock: Up to 3060 MHz
- Game Clock: Up to 2520MHz
Boost Clock is the maximum frequency achievable on the GPU running bursty workload. Boost clock achievability, frequency, and sustainabilty will vary based on several factors, including but not limited to: thermal conditions and variation in application and workloads.
Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.
Stream Processors
4096
Compute Units
64 CUs (3rd Gen RT + 2nd Gen AI Accelerators)
Infinity Cache
64MB
Ray Accelerators
64
AI Accelerator
128
Memory Size/Bus
16GB/256 bit GDDR6
Memory Clock
20 Gbps Effective
Displays
Maximum 4 Displays
Resolution
- HDMI® 2.1b: 7680×4320
- DisplayPort™ 2.1a: 7680×4320
Interface
PCI-Express 5.0 x16
Output
- 2x HDMI® 2.1b
- 2x DisplayPort™ 2.1a
BIOS Support
- UEFI
Game Index
4K
Sapphire Features
- PhantomLink (GC-HPWR / BTF) Power Connector
- New TriXX Feature: Power Protection
Характеристики
| STEALTH Hidden Power Cable | 12V-2x6(H++) External Power Connector (3x8-pin power adapter is also included if your PC's Power Supply Unit does not have 12V-2x6) |
| Ultra-Thin Graphene Thermal Pad | AeroCurve Fan Blade |
| Free Flow | FrameDefense |
| Integrated Cooling Module | Cold Rolled Steel Frame |
| Tri-X Cooling Technology | High TG Copper PCB |
| Optimized Composite Heatpipes | Metal Backplate |
| ARGB Light Bar | Fan Quick Connect |
| Two-Ball Bearing Fans | Premium 16-Phase Digital Power Design |
| Fuse Protection | Intelligent Fan Control |
| Precision Fan Control | TriXX Supported |
