Вентилатори 140mm
be quiet!

Вентилатори 140mm

Артикул №: 1000149387
Категория: Вентилатори
39,99 €
✓ Налично във външен склад

INNOVATIVE TECHNOLOGY

Closed loop motor for persistent rpm

Pure Wings 3 140mm PWM high-speed Triple Pack features a closed loop motor. This technology is comparable with the cruise control in cars. When working against resistance, for example a fan grill or radiator, fans spin slower as a result. The closed loop motor technology constantly monitors the current fan speed and increases it to the target rpm, if necessary. As a result, Pure Wings 3 140mm PWM high-speed Triple Pack always operates at the desired speed, no matter the resistance.

OPTIMIZED TO THE MAX

For unprecedented air pressure in its class

The fan frame outlet is newly designed to minimize air leaks. This benefits especially the radiator performance of Pure Wings 3 140mm PWM high-speed Triple Pack. To reach even higher performance, the fan blades are optimized as well: Their angle is adjusted to achieve even more air pressure, adding up to the extraordinary performance of Pure Wings 3 140mm PWM high-speed Triple Pack.

FOR RADIATORS AND HEATSINKS

Fan blades optimized for high pressure

With a remarkably high air pressure of up to 2.44mm/H2O, Pure Wings 3 140mm PWM high-speed Triple Pack is the best choice for water-cooled and air-cooled systems alike. The 9 airflow-optimized fan blades provide enough air pressure to make this fan work great even in demanding configurations.

ICONIC DESIGN

Streamlined look makes it an instant timeless classic

Pure Wings 3 140mm PWM high-speed Triple Pack trims all the fat. Every part and single detail contribute to the functionality and uncompromising performance. This has also been considered in the design of the fan. All outlines and angles serve a purpose, making Pure Wings 3 140mm PWM high-speed Triple Pack a timeless classic and elegant addition to every gaming PC.

General data

ModelPure Wings 3 140mm | PWM high-speed Triple Pack
Dimensions (mm)140 Да
Color optionBlack Да
Lighting- Да
Fan speed at 100% PWM / 12V (rpm)1800
Noise level at 100% PWM / 12V (dB(A))30.5
Airflow at 100% PWM / 12V (CFM / m3/h)72.2 / 122.6
Air Pressure at 100% PWM / 12V (mm H2O)2.44
Mechanical specifications Да
Dimensions (L x W x H), (mm)140 x 25 x 140
Weight incl. fixed cables (g)188 Да
Bearing technologyRifle Да
Motor technology4-pole fan motor Да
Push pin fixing- Да
Screw fixingYes Да
Cables / Connectors Да
Daisy-chain compatible- Да
Lighting connector- Да
Connector4-pin PWM Да
Cable length (mm)460 Да
Cable sleeve- Да
Performance / Noise Да
Airflow at 100% PWM / 12V (CFM / m3/h)72.2 / 122.6
Air Pressure at 100% PWM / 12V (mm H2O)2.44
Noise level at 100% PWM / 12V (dB(A))30.5
Lifespan (h / 25°C)80,000
Zero RPM mode- Да
Electrical specifications Да
Rated Voltage DC (V)12 Да
Operating Voltage DC (V)5 - 13.2
Input current (A)0.12 Да
Safety current (A)0.5 Да
Input power (W)6 Да
Rated Current LED (A)- Да
Safety certification Да
ApprovalsCE / RoHS / RU / UKCA / WEEE Да
Environmental directives Да
RoHSYes Да
WEEEYes Да
TrimanYes Да
