Arctic
Вентилатори 140mm
Артикул №: 1000036068
Категория:
Вентилатори
21,99 €
✓ Налично във външен склад
Reversed Airflow:
The P14 Pro Reverse is specifically designed for air intake from the back side. It's particularly suitable when conventional fans would compromise the aesthetics.
SOTA Microcontroller:
Reduces motor noise, compensates for load fluctuations, and protects against inrush currents and reverse polarity.
More Power – Less Noise:
An automated measuring and balancing process ensures smooth performance by applying the balancing compound with pinpoint accuracy.
Minimum Gap Dimensions for Maximum Efficiency:
Enables higher static pressure and maximum airflow efficiency.
PST – Easy Cable Management and Synchronized PWM Control:
Thanks to the additional PWM connector, multiple fans can be daisy-chained and controlled simultaneously through a single header.
Optimized FDB Bearing-Shaft Design
A hydrodynamic bearing combined with an extended shaft ensures quieter operation by improving pressure distribution and minimizing vibrations.
Specifications
Operating Ambient Temperature
0–40 °C
Dimensions
140 (L) x 140 (W) x 30 (H) mm
Net Weight
248 g
Fan Speed
400–2650 rpm, PWM controlled
0 rpm below 5 % PWM
Airflow
98 cfm | 166.5 m³/h
Static Pressure
5.1 mmH2O
Fan Bearing
Fluid Dynamic Bearing
Typical Voltage
12 V DC
Start Up Voltage
4 V DC
Current
0.4 A
Cable Lenth
400 mm + 80 mm Daisy-Chain Cable
Connector
4-Pin Fan Plug + 4-Pin Socket
The P14 Pro Reverse is specifically designed for air intake from the back side. It's particularly suitable when conventional fans would compromise the aesthetics.
SOTA Microcontroller:
Reduces motor noise, compensates for load fluctuations, and protects against inrush currents and reverse polarity.
More Power – Less Noise:
An automated measuring and balancing process ensures smooth performance by applying the balancing compound with pinpoint accuracy.
Minimum Gap Dimensions for Maximum Efficiency:
Enables higher static pressure and maximum airflow efficiency.
PST – Easy Cable Management and Synchronized PWM Control:
Thanks to the additional PWM connector, multiple fans can be daisy-chained and controlled simultaneously through a single header.
Optimized FDB Bearing-Shaft Design
A hydrodynamic bearing combined with an extended shaft ensures quieter operation by improving pressure distribution and minimizing vibrations.
Specifications
Operating Ambient Temperature
0–40 °C
Dimensions
140 (L) x 140 (W) x 30 (H) mm
Net Weight
248 g
Fan Speed
400–2650 rpm, PWM controlled
0 rpm below 5 % PWM
Airflow
98 cfm | 166.5 m³/h
Static Pressure
5.1 mmH2O
Fan Bearing
Fluid Dynamic Bearing
Typical Voltage
12 V DC
Start Up Voltage
4 V DC
Current
0.4 A
Cable Lenth
400 mm + 80 mm Daisy-Chain Cable
Connector
4-Pin Fan Plug + 4-Pin Socket
Характеристики
| 140 (L) x 140 (W) | x 30 (H) mm |
| Rpm below 5 % PWM | 0 |
| Cfm | 166.5 m³/h | 98 |
| MmH2O | 5.1 |
| V DC | 12 |
| V DC | 4 |
| Mm + 80 mm Daisy-Chain Cable | 400 |
