Arctic
Вентилатор 92mm
Артикул №: 1000042151
Категория:
Вентилатори
7,99 €
✓ Налично в централен склад
Optimised for High Static Pressure:
The P9 PWM PST CO delivers a focused airflow and guarantees a good airflow even with particularly high static pressure. Therefore, the P9 PWM PST CO is also specially suitable for use on heat sinks, radiators, pinholes and filters.
0 dB Mode - Zero rpm:
The speed of the fan can be throttled down to a standstill via PWM. This allows silent operation in IDLE and at the same time guarantees maximum performance when required. This enables the P9 PWM PST CO to be extremely flexible in adjusting the speed to optimally regulate the airflow for every case.
Specifications
Operating Ambient Temperature
0–40 °C
Dimensions
92 (L) x 92 (W) x 25 (H) mm
Net Weight
105 g
Fan Speed
200–3000 rpm (PWM controlled), 0 rpm below 5 % PWM
Airflow
38.83 cfm | 65.97 m³/h
Static Pressure
3.12 mmH2O
Fan Bearing
Dual Ball Bearing
Typical Voltage
12 V DC
Start Up Voltage
5 V DC
Current
0.12 A
Cable Length
400 mm + 80 mm Daisy-Chain Cable
Connector
4-Pin Fan Plug + 4-Pin Socket
The P9 PWM PST CO delivers a focused airflow and guarantees a good airflow even with particularly high static pressure. Therefore, the P9 PWM PST CO is also specially suitable for use on heat sinks, radiators, pinholes and filters.
0 dB Mode - Zero rpm:
The speed of the fan can be throttled down to a standstill via PWM. This allows silent operation in IDLE and at the same time guarantees maximum performance when required. This enables the P9 PWM PST CO to be extremely flexible in adjusting the speed to optimally regulate the airflow for every case.
Specifications
Operating Ambient Temperature
0–40 °C
Dimensions
92 (L) x 92 (W) x 25 (H) mm
Net Weight
105 g
Fan Speed
200–3000 rpm (PWM controlled), 0 rpm below 5 % PWM
Airflow
38.83 cfm | 65.97 m³/h
Static Pressure
3.12 mmH2O
Fan Bearing
Dual Ball Bearing
Typical Voltage
12 V DC
Start Up Voltage
5 V DC
Current
0.12 A
Cable Length
400 mm + 80 mm Daisy-Chain Cable
Connector
4-Pin Fan Plug + 4-Pin Socket
Характеристики
| 92 (L) | x 92 (W) x 25 (H) mm |
| Cfm | 65.97 m³/h | 38.83 |
| MmH2O | 3.12 |
| V DC | 12 |
| V DC | 5 |
| Mm + 80 mm Daisy-Chain Cable | 400 |
