Noctua
Вентилатор 40mm
Артикул №: 1000044278
Категория:
Вентилатори
16,99 €
✓ Налично в централен склад
Noctua NF-A4x20-PWM
FAN Specification
Size:
40x40x20 mm.
Mounting hole spacing:
32x32 mm.
Connector:
4-Pin PWM
Bearing:
SSO2
Blade Geometry:
A-Series with Flow Acceleration Channels
Frame Technology:
AAO (Advanced Acoustic Optimisation)
Rotational Speed:
5000 RPM
Rotational Speed with L.N.A.:
4400 RPM
Min. Rotational Speed:
1200 RPM
Airflow:
9,4 m³/h
Airflow with L.N.A.:
8,3 m³/h
Acoustical Noise:
14,9 dB(A)
Acoustical Noise with L.N.A.:
12,2 dB(A)
Static Pressure:
2,26 mm. H₂O
Static Pressure with L.N.A.:
1,75 mm. H₂O
Max. Input Power:
0,6 W.
Max. Input Current:
0,05 A.
Voltage:
12 V.
Voltage PWM signal:
5 V.
MTTF:
> 150.000 h.
FAN Specification
Size:
40x40x20 mm.
Mounting hole spacing:
32x32 mm.
Connector:
4-Pin PWM
Bearing:
SSO2
Blade Geometry:
A-Series with Flow Acceleration Channels
Frame Technology:
AAO (Advanced Acoustic Optimisation)
Rotational Speed:
5000 RPM
Rotational Speed with L.N.A.:
4400 RPM
Min. Rotational Speed:
1200 RPM
Airflow:
9,4 m³/h
Airflow with L.N.A.:
8,3 m³/h
Acoustical Noise:
14,9 dB(A)
Acoustical Noise with L.N.A.:
12,2 dB(A)
Static Pressure:
2,26 mm. H₂O
Static Pressure with L.N.A.:
1,75 mm. H₂O
Max. Input Power:
0,6 W.
Max. Input Current:
0,05 A.
Voltage:
12 V.
Voltage PWM signal:
5 V.
MTTF:
> 150.000 h.
Характеристики
| 5000 RPM | Rotational Speed with L.N.A.: |
| 4400 RPM | Min. Rotational Speed: |
| 1200 RPM | Airflow: |
| 9,4 m³/h | Airflow with L.N.A.: |
| 8,3 m³/h | Acoustical Noise: |
| 14,9 dB(A) | Acoustical Noise with L.N.A.: |
| 12,2 dB(A) | Static Pressure: |
| 2,26 mm. H₂O | Static Pressure with L.N.A.: |
| 1,75 mm. H₂O | Max. Input Power: |
