Вентилатор 150mm (round 140mm)
The NF-A15 is a premium quality quiet 140mm fan with a round frame that complies with Noctua’s AAO (Advanced Acoustic Optimisation) standard. The NF-A15’s frame features 120mm mounting holes (105mm spacing) and has been enlarged to 150mm width in order to provide superior performance on today’s high-end CPU coolers. Featuring sophisticated aerodynamic design measures such as Flow Acceleration Channels, the NF-A15 further improves the renowned quiet cooling performance of the award-winning NF-P14. Noctua’s custom designed PWM IC for fully automatic speed control and reference class SSO2 bearings guarantee superb running smoothness and excellent long-term stability. Topped off with modular cabling, a Low-Noise Adaptor and 6 years manufacturer’s warranty, the NF-A15 is a premium choice for the highest demands.
Характеристики
| Размер | 140x150x25 mm |
| Конектор | 4-pin PWM |
| Bearing | SSO2 |
| Blade Geometry | A-Series with Flow Acceleration Channels |
| Frame Technology | AAO (Advanced Acoustic Optimisation) |
| Rotational Speed (+/- 10%) | 1200 RPM |
| Rotational Speed with L.N.A. (+/- 10%) | 900 RPM |
| Min. Rotational Speed (PWM) | 300 RPM |
| Airflow | 115,5 m³/h |
| Airflow with L.N.A | 88,7 m³/h |
| Acoustical Noise | 19,2 dB(A) |
| Acoustical Noise with L.N.A | 13,8 dB(A) |
| Static Pressure | 1,51 mm H2O |
| Static Pressure with L.N.A | 0,89 mm H2O |
| Max. Input Power | 0,96 W |
| Max. Input Current | 0,08 A |
| Напрежение | 12 V |
| MTBF | > 150.000 h |
| Scope of Delivery | Да |
| Low-Noise Adaptor (L.N.A.) | Да |
| 4-Pin Y-Cable | Да |
| 30cm Extension Cable | Да |
| Vibration-Compensators | 4 |
| Fan Screws | 4 |
