Вентилатор 120mm Noctua NF-F12 NE-FD5 industrialPPC
Noctua

Вентилатор 120mm Noctua NF-F12 NE-FD5 industrialPPC

Артикул №: 1000146520
Категория: Вентилатори
34,99 €
✓ Налично във външен склад

Conceived for industrial heavy-duty applications that require enhanced cooling performance and advanced ingress protection, the NF-F12 industrialPPC (Protected Performance Cooling) is a ruggedised high-speed version of the award-winning retail model. The 24V SP variant uses Noctua’s new NE-FD5 high-efficiency single-phase motor driver IC in order to support 24V-based industrial and automotive applications. Its sophisticated inrush current suppression and extreme electrical robustness with extended burst and surge immunity allow it to operate safely in sensitive or hostile electronic environments. Thanks to the outstanding aerodynamic efficiency of the NF-F12 design and the high-performance single-phase motor, the industrialPPC SP version provides superior airflow and pressure capacity while keeping noise and power consumption at a moderate level as against comparable high-speed fans. While its fibre-glass reinforced polyamide construction and certified water and dust protection make the NF-F12 industrialPPC suitable for operation in challenging surroundings, the renowned SSO2 bearing technology guarantees an MTTF of over 150,000hrs. Topped off with Noctua’s trusted reliability and 6-year manufacturer’s warranty, the NF-F12 industrialPPC is an ideal choice for highly demanding applications that require superior flow rates and ultimate dependability.

Характеристики

FAN Specification Размер
120x120x25 mm Mounting hole spacing
105x105 mm Connector & pin-configuration
4-pin PWM Дължина на кабела
40cm Bearing
SSO2 Blade geometry
Heptaperf™ Frame technology
FocusedFlow™ Материал
Fibre-glass reinforced polyamide Ingress protection
IP67 Motor type
Single-phase Rotational speed (+/- 10%)
3000 RPM Min. rotational speed @ 20% PWM (+/-20%)
750 RPM Rotational speed @ 12V (+/- 10%)
1600 RPM Airflow
186,7 m³/h Acoustical noise
43,5 dB(A) Static pressure
7,63 mm H₂O Input power (max.)
4,32 W Input current (max.)
0,18 A Operating voltage
24 V Voltage PWM signal
5 V MTTF
150.000 h Scope of delivery
Fan 4 Fan Screws
