Вентилатор 120mm
Efficient Performance at High Air Resistance:
Thanks to high static pressure, the Pro fans move air effectively through tight spaces. This makes them ideal for radiators, perforated panels, and mesh filters.
Maximum Performance, Redefined:
Revised fan blade design for an optimal balance of performance and smooth operation.
Optimized Bearing-Shaft Design (FDB):
A hydrodynamic bearing combined with an extended shaft ensures quieter operation by improving pressure distribution and minimizing vibrations.
Automated Balancing:
An automated measuring and balancing process ensures exceptional precision and smooth performance by applying the balancing compound with pinpoint accuracy.
PST – PWM-Based Synchronized Fan Control:
An additional PWM connector allows multiple fans to be synchronized in series using a single header.
Характеристики
| Fan Specifications | Fan Speed 600–3000 rpm, PWM controlled ; 0 rpm below 5 % PWM Airflow 77 cfm | 131 m³/h Static Pressure 6.9 mmH2O Fan Bearing Fluid Dynamic Bearing Typical Voltage 12 V DC Start Up Voltage 3.3 V DC Current 0.33 A Cable Length 400 mm + 80 mm Daisy-Chain Cable Connector 4-Pin Fan Plug + 4-Pin Socket |
| RGB Specifications | LEDs 12x A-RGB Gen2 LEDs Current | Voltage 0.40 A | 5 V DC Connector 3-Pin A-RGB Plug + 3-Pin Socket |
