PowerWalker
UPS PowerWalker DC SecureAdapter 10120431
Артикул №: 1000043962
Категория:
UPS
31,99 €
✓ Налично във външен склад
Адаптерът PowerWalker DC 12 V е универсално решение. Заменете вашия 12VDC с нашия UPS, за да защитите вашите устройства от спиране на тока. Така ще предотвратите прекъсване на видео разговори или синхронизиране на данни, ще защитите здравето и имуществото си, като поддържате работещи всички необходими системи за мониторинг.
GENERAL FEATURES
Type DC
Phases (IN-OUT) DC
Form Factor Socket Plug-In
Power Capacity 12VA / 12W
Output Power Factor 1.00
INPUT
Input Voltage Range 90-264 VAC
Frequency Range 50Hz or 60Hz (self-adaptive)
OUTPUT
Waveform Simulated Sine Wave
Nominal Output Voltage 12 VDC
Voltage Regulation (Battery Mode) ±5%
INPUT & OUTPUT CONNECTORS
Input Connector CEE 7/16
Output Type DC Coaxial Connector
TECHNICAL DETAILS
LINE Mode Efficiency [%] (Full Load) 82.0
Battery Mode Efficiency [%] (Full Load) 82.5
Additional Features Lithium Battery
BATTERIES AND AUTONOMY
GENERAL FEATURES
Type DC
Phases (IN-OUT) DC
Form Factor Socket Plug-In
Power Capacity 12VA / 12W
Output Power Factor 1.00
INPUT
Input Voltage Range 90-264 VAC
Frequency Range 50Hz or 60Hz (self-adaptive)
OUTPUT
Waveform Simulated Sine Wave
Nominal Output Voltage 12 VDC
Voltage Regulation (Battery Mode) ±5%
INPUT & OUTPUT CONNECTORS
Input Connector CEE 7/16
Output Type DC Coaxial Connector
TECHNICAL DETAILS
LINE Mode Efficiency [%] (Full Load) 82.0
Battery Mode Efficiency [%] (Full Load) 82.5
Additional Features Lithium Battery
BATTERIES AND AUTONOMY
Характеристики
| BATTERIES AND AUTONOMY | Batteries 1x 3.7V/2.6Ah |
| DC Voltage 1x 3.7V | Recharge Time 3h to 90% |
| Full Load Backup Time [min] 25.0 | Half Load Backup Time [min] 50.0 |
| COMMUNICATION | Communication N/A |
| Software N/A | ENVIRONMENT |
| Noise Level < 30dB | Fan Logic No fan |
| Temperature 0°C – 40°C | Humidity 5% – 90% RH (non-condensing) |
| IP IP 51 | LOGISTICS |
| Package Content Manual | Manual Languages EN, DE, PL, FR |
| EAN 4260074977943 | Product Dimensions (DxWxH) [mm] 74 x 68 x 42 mm |
| Product Weight [kg] 0.2 | Package Dimensions (DxWxH) [mm] 108 x 115 x 54 mm |
| Package Weight [kg] 0.3 | Pcs. per Outer Carton 28 |
| Pcs. per Layer 224 | Pcs. per Pallet 2688 |
