5SC 1000i
General:
Topology Line-interactive high frequency with booster + fader, pure sinewave output
Configuration Tower
Part Number 5SC1000i
Color Black
Rating (VA/Watts) 1000/700
Dimensions (H x W x D, mm) 210 x 150 x 340
Weight (kg) 11.1
Electrical Input:
Input Voltage Range 184V-276V
Nominal Voltage 230V
Input frequency Range Without Using Batteries 45–55Hz (50Hz system), 55–65Hz (60Hz system)
Electrical Output:
Voltages 230V (+6/–10 %) (Adjustable to 220V/230V/240V)
Output Frequency 50/60Hz +/–0.1 % (autosensing)
Battery:
Battery Management ABM®, Automatic battery test, deep discharge protection
Communications:
Communication Ports 1 USB port + 1 RS232 serial port (USB and RS232 ports cannot be used simultaneously)
743172045164
General:
Topology Line-interactive high frequency with booster + fader, pure sinewave output
Configuration Tower
Part Number 5SC1000i
Color Black
Rating (VA/Watts) 1000/700
Dimensions (H x W x D, mm) 210 x 150 x 340
Weight (kg) 11.1
Electrical Input:
Input Voltage Range 184V-276V
Nominal Voltage 230V
Input frequency Range Without Using Batteries 45–55Hz (50Hz system), 55–65Hz (60Hz system)
Electrical Output:
Voltages 230V (+6/–10 %) (Adjustable to 220V/230V/240V)
Output Frequency 50/60Hz +/–0.1 % (autosensing)
Battery:
Battery Management ABM®, Automatic battery test, deep discharge protection
Communications:
Communication Ports 1 USB port + 1 RS232 serial port (USB and RS232 ports cannot be used simultaneously)
743172045164
Характеристики
| Part Number 5SC1000i | Color Black |
| Rating (VA/Watts) 1000/700 | Dimensions (H x W x D, mm) 210 x 150 x 340 |
| Weight (kg) 11.1 | Electrical Input: |
| Input Voltage Range 184V-276V | Nominal Voltage 230V |
