TP-Link
Точка за достъп TP-Link Omada EAP683 LR
Артикул №: 1000050803
Категория:
Аксеспойнт/Репитер Безжични
189,99 €
✓ Налично във външен склад
EAP683 UR
AX6000 Ceiling Mount WiFi 6 Access Point
- Up to 5952 Mbps WiFi 6 Speeds: 1148 Mbps on 2.4 GHz + 4804 Mbps on 5 GHz†
- Ultra-range wireless coverage by 4×4 MIMO dual-band internal antennas with high transmission power.
- Supports WiFi 6 technologies, such as HE160, 1024-QAM, etc.‡
- Integrates with the Omada SDN platform for centralized management.
- Advanced Features: Omada Mesh, Seamless Roaming, and more.§
- PoE+ Powered: Supports both 802.3at PoE+ and DC (adapter not included).
ХАРДУЕРНИ ХАРАКТЕРИСТИКИ
| Интерфейс | 1× 2.5 Gigabit PoE+ Port |
| Бутон | Reset |
| Захранване | • 802.3at PoE · • 12 V / 2 A DC · · Note：Power adapter is not included |
| Консумирана енергия | • EU: 20.43W · • US: 23.69W |
| Размери (Ш x Д x В ) | 8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm) |
| Тип антена | Internal Omni · • 2.4 GHz: 4× 4 dBi · • 5 GHz: 4× 5 dBi |
| Bluetooth | Да |
| Монтаж | Ceiling /Wall Mounting (Kits included) |
БЕЗЖИЧНИ ХАРАКТЕРИСТИКИ
| Coverage | 185㎡(2000ft²)*** |
| Concurrent Clients | 510+** |
| Безжични стандарти | IEEE 802.11ax/ac/n/g/b/a |
| Честотa | 2.4 GHz and 5 GHz |
| Скорост на сигнала | • 5 GHz: Up to 4804 Mbps · • 2.4 GHz: Up to 1148 Mbps |
| Безжични функции | • 1024-QAM · • 4× Longer OFDM Symbol · • OFDMA · • Multiple SSIDs (Up to 16 SSIDs, 8 for each band) · • Enable/Disable Wireless Radio · • Automatic Channel Assignment · • Transmit Power Control (Adjust Transmit Power on dBm) · • QoS(WMM) · • MU-MIMO · • HE160 (160 MHz Bandwidth) · • Seamless Roaming § · • Omada Mesh§ · • Band Steering · • Load Balance · • Airtime Fairness · • Beamforming · • Rate Limit · • Reboot Schedule · • Wireless Schedule · • Wireless Statistics based on SSID/AP/Client |
| Безжична сигурност | • Captive Portal Authentication§ · • Access Control · • Wireless Mac Address Filtering · • Wireless Isolation Between Clients · • SSID to VLAN Mapping · • Rogue AP Detection · • 802.1X Support · • WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| Предавателна мощност | • CE: <20 dBm(2.4 GHz, EIRP) · <23 dBm(5 GHz, band1 & band2, EIRP) · <28 dBm(5 GHz, band3, EIRP) · · • FCC: <26 dBm (2.4 GHz) · <26 dBm (5 GHz) |
MANAGEMENT
| Omada App | Да |
| Centralized Management | • Omada Hardware Controller (OC300) · • Omada Hardware Controller (OC200) · • Omada Software Controller · • Omada Cloud-Based Controller |
| Cloud Access | Yes. Require the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller |
| Сигнали по електронна поща | Да |
| Управление Вкл/Изкл на LED | Да |
| Управление на контрола на достъпа по МАС адрес | Да |
| SNMP | v1, v2c, v3 |
| Влизане в системата Локално/Отдалечение | Local/Remote Syslog |
| SSH | Да |
| Уеб-базирано управление | HTTP/HTTPS |
| L3 управление | Да |
| Управление на множество сайтове | Да |
| Управление на VLAN | Да |
| Zero-Touch Provisioning | Yes. Require the use of Omada Cloud-Based Controller |
ДРУГИ
| Сертификати | CE,FCC,RoHS |
| Системни изисквания | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
| Околна среда | • Operating Temperature: 0–40 ℃ (32–104 ℉) · • Storage Temperature: -40–70 ℃ (-40–158 ℉) · • Operating Humidity: 10–90% RH non-condensing · • Storage Humidity: 5–90% RH non-condensing |
