Точка за достъп Mikrotik hAP ax S (E62iUGS-2axD5axT)
hAP ax S
Our most cost-effective Wi-Fi 6 access point yet. Triple-chain 5 GHz radio (up to 900 Mbit/s throughput), dual-band Wi-Fi 6, 5x Gigabit Ethernet ports, and a 2.5G SFP. Powered by a dual-core ARM CPU, with PoE-in/PoE-out flexibility, a standard DC jack, USB, and a sturdy high-end enclosure that can be mounted on the wall.
Meet the new hAP ax S
Our most cost-effective Wi-Fi 6 access point yet
It costs far less than most mid-range, mass-produced routers… while delivering far more flexibility and longevity right out of the box!
Triple-chain 5 GHz:
the key to stable, gigabit-class Wi-Fi
The new hAP ax S features a triple-chain 5 GHz radio that achieves real-world throughput of around 800–900 Mbit/s. That means smooth streaming, faster downloads, and stable performance across multiple devices – even in crowded environments.
It’s also perfect as a dedicated Wi-Fi 6 VR streaming access point for PC VR headsets, offering higher resolution and lower latency without the cables. Unlike single-purpose “gaming” access points, the hAP ax S gives you the full performance, flexibility, and future-proofing of RouterOS v7!
Характеристики
| Product code E62iUGS-2axD5axT | Да |
| Architecture ARM | 32bit |
| CPU EN7562CT | Да |
| CPU core count | 2 |
| CPU nominal frequency | 950 MHz |
| CPU Threads count | 2 |
| Switch chip model EN7523 | Да |
| RouterOS license | 4 |
| Operating System RouterOS v7 | Да |
| Size of RAM | 512 MB |
| Storage size | 128 MB |
| Storage type NAND | Да |
| MTBF Approximately | 100'000 hours at 25C |
| Tested ambient temperature -40°C to | 70°C |
| Wireless capabilities | Да |
| Безжична | 2.4 GHz Max data rate 574 Mbit/s |
| Безжична | 2.4 GHz Number of chains 2 |
| Безжична | 2.4 GHz standards 802.11b/g/n/ax |
| Antenna gain dBi for | 2.4 GHz 5.5 |
| Безжична | 2.4 GHz chip model MT7916 |
| Безжична | 2.4 GHz generation Wi-Fi 6 |
| Безжична | 5 GHz Max data rate 2400 Mbit/s |
| Безжична | 5 GHz Number of chains 3 |
| Безжична | 5 GHz standards 802.11a/n/ac/ax |
| Antenna gain dBi for | 5 GHz 6.5 |
| Безжична | 5 GHz chip model MT7976 |
| Безжична | 5 GHz generation Wi-Fi 6 |
| WiFi speed AX3000 | Да |
| Ethernet | Да |
| 10/100/1000 Ethernet ports 5 | Да |
| Number of | 1G Ethernet ports with PoE-out 1 |
| Fiber | Да |
| SFP ports | 1 (2.5G supported) |
| Peripherals | Да |
| Number of USB ports | 1 |
| USB Power Reset | Да |
| USB slot type USB type A | Да |
| Max USB current (A) | 1 |
| Powering | Да |
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input Voltage | 12-28 V |
| Max power consumption | 34 W |
| Max power consumption without attachments | 11 W |
| PoE in Passive PoE | Да |
| Cooling type Passive | Да |
| PoE in input Voltage | 18-28 V |
| PoE-out | Да |
| PoE-out ports Ether5 | Да |
| PoE out Passive PoE | Да |
| Low voltage PoE-Out current limit | 0.6 A |
| Max total out (A) | 0.6 A |
| Total output current | 0.6 |
| Total output power | 16.8 |
