Точка за достъп D-LINK DWL-3600AP

D-LINK DWL-3600AP Wireless N Unified Access Point
Up to 40 users

• Wi-Fi Interface
802.11b/g/n 2.4 GHz

• LAN Interface
10/100/1000 Gigabit Ethernet

• Antenna
2x2 MIMO embedded antenna with 4 internal antennas

• Antenna Gain
4.7 dBi

• Power Method
IEEE 802.3af Power Over Ethernet or external power adapter

• Wireless Frequency
802.11b/g/n: 2.4 GHz - 2.497 GHz

• Data Transfer Rate
802.11n: 6.5 Mbps-130 Mbps (20 MHz)
6.5 Mbps- 300 Mbps (40 Mbps)
802.11g: 54, 48, 36, 24, 18, 12, 9 and 6 Mbps
802.11b: 11, 5.5, 2 and 1 Mbps

• Operation Channel (2.4 GHz)
11 channels for United States

• System Management
HTTP/HTTPS Web-based User Interface
SNMP, SSH, Telnet Command Line

• SSID
16 SSID
Station Isolation

• Wireless Security
WEP
Dynamic WEP
WPA Personal/Enterprise
WPA2 Personal/Enterprise

• Detection & Prevention
Rogue and Valid AP Classification

• Authentication
MAC Address Filtering
802.1x

• Power Adapter
5V/2.5A

• Power over Ethernet
48 VDC +/- 10%

• Stand-Alone Mode
WEP/WPA/WPA2 Security
Rogue AP Detection
Station Isolation
MAC Address Filtering
AP Load Balancing Setup
WDS
AP Clustering
QoS/WMM
Local Storage Configuration

• Managed Mode (Managed by D-Link Wireless Switch/ Wireless Controller)
Centralized Management
Centralized Firmware Dispatch
Visualized AP Management Tool
Auto-Power Adjustment
Dynamic Auto-Channel Selection
L2 Fast Roaming
L3 Fast Roaming
Captive Portal
WEP/WPA/WPA2 Security
Rogue AP Detection
Rogue AP Mitigation
WIDS
Station Isolation
MAC Address Filtering
AP Load Balancing Setup
WDS
QoS/WMM

• Dimensions
7.99” x 7.99 “x 1.89” (203 x 203 x 48 mm)

• Weight
1.4 lbs (635 g)

• Operating Temperature
32°F to 104°F (0° to 40°C)

• Operating Humidity
10% to 90% non-condensing

• EMI/EMC/RF
FCF Class B
CE Class B
C-tick
IC
VCCI
NCC
TELEC
Wi-Fi®

• Safety
cUL, LVD (EN60950-1)
UL2043
