Ubiquiti
Суич Ubiquiti USW-Pro-Max-48
Артикул №: 1000137538
Категория:
Мрежови адаптери
777,99 €
✓ Налично във външен склад
Max. power consumption100W
Layer 2 featuresIGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs
Layer 3 featuresDHCP for locally-managed networks DHCP relay Inter-VLAN routing between networks on same switch Static routing between local networks Network isolation with ACLs
Характеристики
| Ubiquiti USW-Pro-Max-48 | |
| Dimensions442 x 325 x 44 mm (17.4 x 12.8 x 1.7") | |
| WeightWithout mounting brackets: 4.8 kg (10.6 lb) With mounting brackets: 4.9 kg (10.8 lb) | |
| Enclosure materialSGCC steel | |
| Management interfaceEthernet In-Band | |
| Networking interface(32) GbE RJ45 ports (16) 1/2.5 GbE RJ45 ports (4) 10G SFP+ ports | |
| Total non-blocking throughput112 Gbps | |
| Switching capacity224 Gbps | |
| Forwarding rate166.656 Mpps | |
| Power method(1) Universal input, 100—240V AC, 50/60 Hz (1) USP-RPS DC input | |
| Power supplyAC/DC, internal, 100W | |
| Supported voltage range100—240V AC | |
| LCM display(1) 1.3" touchscreen | |
| ButtonFactory reset | |
| Ambient operating temperature-5 to 40° C (23 to 104° F) | |
| Ambient operating humidity10 to 90% noncondensing | |
| CertificationsCE, FCC, IC | |
| EthernetLocating Speed/link Native VLAN/network | |
| SFP+Locating Speed/link Native VLAN/network | |
| SystemStatus | |
| RPSStatus | |
| UniFi NetworkVersion 8.0.24 and later |
