TP-Link
Суич TP-Link Omada SG6428X
Артикул №: 1000137366
Категория:
Мрежови адаптери
1 930,99 €
✓ Ограничена наличност
Omada 24-Port Gigabit Stackable L3 Managed Switch with 4 10G Slots
| 24× Gigabit RJ45 ports and 4× 10 Gbps SFP+ slots | Да |
| Gbps switching capacity per unit | 128 |
| L3 features | RIP, OSPF, ECMP, VRRP, PIM-DM, PIM-SM, and DHCP Server/Relay |
| Security Strategies | ACL, Port Security, DoS Defend, 802.1X |
| Centralized cloud management via the Omada SDN controller | Да |
| Standalone management via web, CLI, SNMP, and RMON | Да |
Omada SDN
| HARDWARE FEATURES | Interface: • 24× 10/100/1000 Mbps RJ45 Ports · • 4× 10G SFP+ Slots · • 2× USB 2.0 Ports · • 1× RJ45 Console Port · • 1× USB Type-C Console Port · • 1× RJ45 Management Port Fan Quantity: Four Internal Fixed Fans Power Supply: Two Internal Fixed Power Supply Modules (100–240 VAC, 50/60 Hz) Dimensions ( W x D x H ): 17.3 × 15.0 × 1.7 in (440 × 380 × 44 mm) Mounting: Rackmountable Max Power Consumption: 28.4 W (220 V/50 Hz) Max Heat Dissipation: 96.91 BTU/hr (220 V/50 Hz) |
| PERFORMANCE | Switching Capacity: 128 Gbps per Unit Stacking: • Stacking Number: 8 · • Stacking Port: 10G SFP+ Slot (all uplink ports can be used as stacking ports) · • Stack Bandwidth: Up to 80 Gbps (4 stack ports) Packet Forwarding Rate: 95.2 Mpps MAC Address Table: 32 K Packet Buffer Memory: 3 MB Jumbo Frame: 9 KB |
| SOFTWARE FEATURES | Quality of Service: • Class of Service · - 8 Queues of Priority · - Port Priority · - IEEE 802.1p Priority · - DSCP Priority · - Queue Min-Bandwidth · - Schedule Mode (SP, WRR, SP+WRR) · • Bandwidth Control · - Rate Limit · - Storm Control · • Voice VLAN · • User-Defined OUI · • Smoother Performance · • Action for Flows · - QoS remark (802.1P Remark, DSCP Remark) · L3 Features: • IP Interfaces: · - IPv4: Max 256, IPv6: Max 256 · • Static Routing · - Max 1,024, IPv6: Max 512 · • Host Route Table: Max 6,100 entries · • RIP: Version v1/v2, Max 8,190 · • OSPF: Version v2/v3; v2: Max 8,190, v3: Max 4,097 · • VRRP: Version v2/v3, Max 64 groups · • ECMP: 256 entries, max 32 ECMP Nexthops per Destination · • Static ARP: 512 static entries · • Dynamic ARP: 7,680 dynamic entries · • Proxy ARP · • DHCP Server: · - Max 8K IP Pools · - Max 1,000 Manual Binding Entries · • DHCP Relay: · - Relayed Interface · - Relayed VLAN L2 and L2+ Features: • Link Aggregation · • Spanning Tree Protocol · • Port-based and VLAN-based Loopback Detection · • 802.3x Flow Control · • Supports 2,048 IGMP groups · • ERPS · • Mirroring · • RSPAN · • MAC Address Table · • PIM-DM (IPv4) · • Multicast · - IGMP Snooping · - MLD Snooping · - L2 Multicast Table · - Fast Leave · - Multicast VLAN Registration (MVR) · - Static Multicast IP · - Multicast Filtering · Advanced Features: • Automatic Device Discovery† · • Batch Configuration† · • Batch Firmware Upgrading† · • Intelligent Network Monitoring† · • Abnormal Event Warnings† · • Unified Configuration† · • Reboot Schedule† · · ISP Features: · • 802.3ah Ethernet Link OAM · • L2PT (Layer 2 Protocol Tunneling) · • Device Link Detect Protocol (DLDP) · • DDM · • sFlow VLAN: • Max 4K VLAN Group (802.1q VLAN) · • 802.1Q Tagged VLAN · • MAC VLAN Entries: 200 · • Multicast VLAN · • Management VLAN · • VLAN VPN (QinQ): Max 256 entries · • GVRP · • Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries · • VLAN VPN · • Voice VLAN · • Private VLAN Security: • Port Isolation · • CPU-Defend · • ARP Inspection (Dynamic ARP Inspection) · • DoS Defend · • IP-MAC-Port Binding · -1,024 Entries · - DHCP Snooping · - ARP Inspection · - IPv4 Source Guard · • IPv6-MAC · -Port Binding · -1,024 Entries · - DHCPv6 Snooping · - ND Detection · - ND Snooping · - IPv6 Source Guard · • DHCP Filter · • Static/Dynamic Port Security · - Up to 64 MAC addresses per port · • Broadcast/Multicast/Unknown-unicast Storm Control · - kbps/ratio control mode · • 802.1X · - Port base authentication · - Mac base authentication · - VLAN Assignment · - MAB · - Guest VLAN · - RADIUS authentication and accountability support · • AAA (including TACACS+) · • Secure web management through HTTPS with SSLv3/TLS 1.2 · • Secure Command Line Interface (CLI) management with SSHv2 · • IP/Port/MAC-based access control |
| MANAGEMENT | Omada App: Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. Centralized Management: • Omada Cloud-Based Controller · • Omada Hardware Controller · • Omada Software Controller Cloud Access: Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. Zero-Touch Provisioning: Yes. Requiring the use of the Omada Cloud-Based Controller. Management Features: • Web-based GUI · • Command Line Interface (CLI) through console port, telnet · • SNMPv1/v2c/v3 · - Trap/Inform · - RMON (1, 2, 3, 9 groups) · • SDM Template · • DHCP/BOOTP Client · • 802.1ab LLDP/LLDP-MED · • DHCP Auto Install · • Dual Image, Dual Configuration · • CPU Monitoring · • Cable Diagnostics · • Password Recovery · • SNTP · • System Log · • EEE |
