TP-Link
Суич TP-Link Omada DS110GMP
Артикул №: 1000137336
Категория:
Мрежови адаптери
177,99 €
✓ Ограничена наличност
TP-Link Omada DS110GMP
Omada 10-Port Gigabit Unmanaged Desktop Switch with 8-Port PoE+
- 9× Gigabit RJ45 ports, and 1× Gigabit combo SFP/RJ45 Port
- 8× PoE+ ports transfer data and power via a single cable with a total power budget of 123 W
- Compliance with IEEE 802.3af/at PoE+, the switch supports PoE Power up to 30 W for each PoE port
- Up to 250 m (820ft) data and power transmission range under Extend Mode
- Priority Mode ensures high priority of ports 1–2 to guarantee the quality of the sensitive applications
- Isolation Mode allows one-click client traffic separation for higher security and performance
- Automatically reboots your dropped or unresponsive PoE-powered devices with PoE Auto Recovery.
- Plug and Play. No configuration or central management required.
- Fanless design reduces power consumption and works silently in its location
Power over Ethernet, Flexible Network Deployment
| Specs | Да |
| HARDWARE FEATURES | Interface: • 9× 10/100/1000 Mbps RJ45 Ports · • 1× 1000 Mbps Combo SFP/RJ45 Port · • AUTO Negotiation · • AUTO MDI/MDIX Network Media: • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) · • EIA/TIA-568 100Ω STP (maximum 100m) · • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) · • EIA/TIA-568 100Ω STP (maximum 100m) · • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) · • EIA/TIA-568 100Ω STP (maximum 100m) Fan Quantity: Fanless Physical Security Lock: Yes External Power Supply: External Power Adapter (Output: 53.5VDC / 2.43A) Packet Forwarding Rate: 14.88 Mpps PoE Ports (RJ45): • Standard: 802.3 af/at compliant · • PoE Ports: Ports 1–8 · • Power Supply: 123 W Mac Address Table: 4K Jumbo Frame: 16 KB Switching Capacity: 20 Gbps Dimensions ( W x D x H ): 8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm) Max Power Consumption: • 7.93 W (220V / 50Hz with no PD connected) · • 141.40 W (220V / 50Hz with 123 W PD connected) Max Heat Dissipation: • 27.04 BTU/h (220V / 50Hz with no PD connected) · • 482.17 BTU/h (220V / 50Hz with 123 W PD connected) |
| SOFTWARE FEATURES | Transmission Method: Store-And-Forward Advanced Functions: • Compatible With IEEE 802.3af/at Compliant PDs · • Extend Mode: Ports 1–4 · • Priority Mode: Ports 1–2 · • Isolation Mode: Ports 1–4/5-8 · • PoE Auto Recovery: Ports 1-8 · • Mac Address Auto-Learning and Auto-Aging · • IEEE802.3x Flow Control for Full-Duplex Mode and Backpressure for Half-Duplex Mode |
