TP-Link
Суич TP-Link DS106P
Артикул №: 1000137107
Категория:
Мрежови адаптери
33,99 €
✓ Налично във външен склад
TP-Link DS106P
Omada 6-Port 10/100Mbps Unmanaged Desktop Switch with 4-Port PoE+
- 6× 10/100 Mbps RJ45 ports
- 4× PoE+ ports transfer data and power on individual cables
- Works with IEEE 802.3af/at compliant PDs
- Supports PoE Power up to 30 W for each PoE port
- Supports PoE Power up to 67 W for all PoE ports*
- Up to 250m (820ft) data and power transmitting range under Extend Mode**
- Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application
- PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
- Plug and Play. No configuration or central management required.
Power over Ethernet, Flexible Network Deployment
Compliant with the IEEE 802.3af/at PoE standards, the switch supports a total PoE power budget of 67 W with 30 W max per PoE+ port. When total power consumption exceeds 67 W, the intelligent power management will cut the lower priority ports power to protect devices from damage.
Характеристики
| HARDWARE FEATURES | Interface: • 6× 10/100 Mbps RJ45 Ports (ports 1–4 support 802.3af/at PoE+) · • AUTO Negotiation · • AUTO MDI/MDIX · Network Media: • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) · • EIA/TIA-568 100Ω STP (maximum 100m) · • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) · • EIA/TIA-568 100Ω STP (maximum 100m) · Fan Quantity: Fanless Physical Security Lock: Yes External Power Supply: External Power Adapter (Output: 53.5 V DC / 1.31 A) Packet Forwarding Rate: 0.8928 Mpps PoE Ports (RJ45): • Standard: 802.3 af/at compliant · • PoE Ports: Ports 1–4 · • Power Supply: 67 W · Mac Address Table: 2K Jumbo Frame: 2 KB Switching Capacity: 1.2 Gbps Dimensions ( W x D x H ): 6.2 x 4.0 x 1.0 in (158 x 101 x 25 mm) Max Power Consumption: • 2.52 W (220 V / 50 Hz, no PD connected) · • 75.4 W (220 V / 50 Hz, with 67 W PD connected) Max Heat Dissipation: • 8.59 BTU/h(no PD connected) · • 257.11 BTU/h(with 67 W PD connected) · |
| SOFTWARE FEATURES | Transmission Method: Store-And-Forward Advanced Functions: • Compatible With IEEE 802.3af/at Compliant PDs · • Extend Mode: Ports 1–4 · • Priority Mode: Ports 1–2 · • PoE Auto Recovery: Ports 1-4 · • Mac Address Auto-Learning and Auto-Aging · • IEEE802.3x Flow Control For Full-Duplex Mode and Backpressure for Half-Duplex Mode |
