Switch D-Link GO-SW-8E
Features
High-Speed Networking
Eight 10/100 Mbps Fast Ethernet ports
Full/half-duplex for Ethernet/Fast Ethernet speeds
Reliability
IEEE 802.3x flow control
Store-and-forward switching scheme
RoHS compliant
Easy Setup
Plug-and-play installation
Auto MDI/MDIX crossover for all ports
D-Link Green Technology
IEEE 802.3az Energy Efficient Ethernet
Port standby
Cable length detection
Link status detection
Stylish Design
Compact lightweight chassis
Ports located conveniently at the rear
Noise-free operation
Technical Specifications
General
Device Interfaces
Eight 10/100 Fast Ethernet LAN ports
Functionality
Advanced Features
Green Ethernet
1.6 Gbps switching fabric
Auto MDI/MDIX crossover for all ports
Secure store-and-forward switching scheme
Compliance with IEEE802.3az EEE power saving
Full/half-duplex for Ethernet/Fast Ethernet speeds
IEEE 802.3x Flow Control
Plug-and-play installation
RoHS compliant
Supports 2048-byte Jumbo Frames
Protocol
CSMA/CD
Data Transfer
Rates Ethernet:
Features
High-Speed Networking
Eight 10/100 Mbps Fast Ethernet ports
Full/half-duplex for Ethernet/Fast Ethernet speeds
Reliability
IEEE 802.3x flow control
Store-and-forward switching scheme
RoHS compliant
Easy Setup
Plug-and-play installation
Auto MDI/MDIX crossover for all ports
D-Link Green Technology
IEEE 802.3az Energy Efficient Ethernet
Port standby
Cable length detection
Link status detection
Stylish Design
Compact lightweight chassis
Ports located conveniently at the rear
Noise-free operation
Technical Specifications
General
Device Interfaces
Eight 10/100 Fast Ethernet LAN ports
Functionality
Advanced Features
Green Ethernet
1.6 Gbps switching fabric
Auto MDI/MDIX crossover for all ports
Secure store-and-forward switching scheme
Compliance with IEEE802.3az EEE power saving
Full/half-duplex for Ethernet/Fast Ethernet speeds
IEEE 802.3x Flow Control
Plug-and-play installation
RoHS compliant
Supports 2048-byte Jumbo Frames
Protocol
CSMA/CD
Data Transfer
Rates Ethernet:
Технически характеристики
| Ethernet | 14,880 pps per port |
| Fast Ethernet | 148,800 pps per port |
| Per port | Link/Activity |
| Per device | Мощност |
| Power On (Standby) | AC input:2.0472 Btu/h |
| Maximum | AC input:7.47228 Btu/h |
| Power On (Standby) | DC input: 0.36 watts, AC input: 0.6 watts |
| Maximum | DC input: 1.78 watts, AC input: 2.19 watts |
| Link Up | EEE mode: DC input: 0.75 watts AC input: 1.1. watts |
| Operating | 0 to 50 °C (14 to 158 °F) |
| Капацитет за съхранение | -10 to 70 °C (14 to 158 °F) |
| Operating | 10% to 90% non-condensing |
| Капацитет за съхранение | 5% to 90% non-condensing |
