Cudy GS105D
Model
GS105D
Interfaces
5x 10/100Base-TX Port
Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Protocol
CSMA/CD
Data Rate
10/100/1000Mbps
Transmission Method
Store-and-Forward
Switching Features
MAC address auto-learning and auto-aging Half and Full Duplex 1Gbps backplane bandwidth
LED Indicators
LAN~LAN5, Power
MAC Address Table
2K entries per device
Power Supply
DC 5V 0.5A
Dimensions W*D*H
100mm x 74mm x 27mm
Weight
135g
Operating Temperatur
0°C~40°C (32°F~104°F)
Storage Temperature
-40°C~70°C (-40°F~158°F)
Relative Humidity
10%~90%, non-condensing
Storage Humidity
5%~95%, non-condensing
Package Contents
1 x Power Adapter；1 x Switch；1 x User Manual
Model
GS105D
Interfaces
5x 10/100Base-TX Port
Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Protocol
CSMA/CD
Data Rate
10/100/1000Mbps
Transmission Method
Store-and-Forward
Switching Features
MAC address auto-learning and auto-aging Half and Full Duplex 1Gbps backplane bandwidth
LED Indicators
LAN~LAN5, Power
MAC Address Table
2K entries per device
Power Supply
DC 5V 0.5A
Dimensions W*D*H
100mm x 74mm x 27mm
Weight
135g
Operating Temperatur
0°C~40°C (32°F~104°F)
Storage Temperature
-40°C~70°C (-40°F~158°F)
Relative Humidity
10%~90%, non-condensing
Storage Humidity
5%~95%, non-condensing
Package Contents
1 x Power Adapter；1 x Switch；1 x User Manual
Характеристики
| Модел | GS105D |
| Interfaces | 5x 10/100Base-TX Port |
| Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Protocol | CSMA/CD |
| Data Rate | 10/100/1000Mbps |
| Transmission Method | Store-and-Forward |
| Switching Features | MAC address auto-learning and auto-aging Half and Full Duplex 1Gbps backplane bandwidth |
| LED Indicators | LAN~LAN5, Power |
| MAC Address Table | 2K entries per device |
| Захранване | DC 5V 0.5A |
| Dimensions W*D*H | 100mm x 74mm x 27mm |
| Тегло | 135g |
| Operating Temperatur | 0°C~40°C (32°F~104°F) |
| Температура на съхранение | -40°C~70°C (-40°F~158°F) |
| Relative Humidity | 10%~90%, non-condensing |
| Storage Humidity | 5%~95%, non-condensing |
| Съдържание на пакета | 1 x Power Adapter；1 x Switch；1 x User Manual |
