| PoE ParametersPoE Standard |
IEEE802.3af /IEEE802.3at |
| Max each port |
15.4W ( IEEE 802.3af )Max each port：30W ( IEEE 802.3at ) |
| PoE compatibility |
IEEE 802.3af/at adaptive |
| PoE port output |
DC48-55V |
| Power Pin |
Power over spare pairs 1/2(+) , 3/6 (-) |
| Network Media10BASE-T |
Cat 6 UTP(≤250 meter)100BASE-TX: Cat5 or more UTP (≤100 meter)1000BASE-TX: Cat5 or more UTP (≤100 meter) |
| OpticalMultiMode Fiber |
850nm, 1310nm,Transmission Distance: 550m/2KmSingle-Mode Fiber: 1310nm, 1550nm,Transmission Distance: 20/40/60/80/100/120km |
| Performance SpecificationBandwidth |
10.8Gbps |
| MAC Address |
2K |
| Packet Buffer Memory |
1M |
| Packet Forwarding Rate |
8Mpps |
| Forwarding Mode |
Store-And-Forward |
| Power SupplyProduct Input Voltage |
AC100-240V 50/60HzPower Budget: 300W |
| Led indicatorSWDIP indicator (Green)OFF |
Normal Vlan: Lighting Extend: Slow flash |
| Working EnvironmentOperating Temperature |
-20℃ ~ 50℃ |
| Температура на съхранение |
-40℃ ~ 85℃ |
| Operating Humidity |
Max 90%, non-condensing |
| Storage Humidity |
Max 95%, non-condensing |
| Working Height |
Max to 10,000 feet (3,000 meters） |
| Storage Height |
Max to 10,000 feet (3,000 meters) |
| Physical ParameterProduct Dimension (L*W*H) |
320mm*210mm*46mm |
| Package Dimension (L*W*H) |
375mm*270mm*85mm |
| N.W |
1.9KG |
| G.W |
2.4KG |
