Fibaro
Смарт превключвател Fibaro Walli Dimmer Anthracite (FGWDEU-111-8)
Артикул №: 1000139450
Категория:
Smart home
63,99 €
✓ Налично във външен склад
The ultimate Z-Wave Plus Wall-Mounted Switch for control and dimming lightning wirelessly.
- Wireless Z-Wave control and dimming lighting
- Monitor and analyse energy usage
- Beautiful colour LED
- Z-Wave Plus Certified
- Color - Anthracite
FIBARO Wall Roller Shutter is an intelligent wall switch designed for controlling and dimming lighting using the Z-Wave network.
It measures active power and energy consumed by the controlled load.
You can install it with FIBARO cover plate or other compatible: GIRA System 55 (Standard 55, E2, Event, Event Clear), Legrand Céliane or Schneider Odace (required parts and limitations were described in the full manual).
Technical details
| Размери | Height 86 mm, Width 86 mm, Depth 51 mm |
| Захранване | 110-230V~50/60 Hz |
| Recommended external overcurrent protection | 10A type B circuit breaker (EU), 13A type B circuit breaker (Sweden) |
| Recommended wires | cross-section area between 1.5-4.0mm2 |
| For installation in boxes | Ø = 60mm, depth ≥ 40mm |
| Работна температура | 0-35 °C |
| Ambient humidity | 10–95% RH without condensation |
| Compatible load types | Resistive loads Conventional incandescent and halogen light sources |
| Resistive-inductive loads Ferromagnetic transformers | Да |
| Rated load current | 50-350W – resistive loads(incandescent and halogen) |
| 5-50W – with Bypass 2 | fluorescent tube lamp or LED |
| Number of controlled loads | 1 |
| Active element | semiconductor electronic switch ε |
| Radio protocol | Z-Wave |
| Transmit power | EIRP max 6dBm |
| Radio frequency | 868.4 or 869.85 MHz EU |
| Range | up to 40m indoors(depending on terrain and building structure) |
