MikroTik
Рутер MikroTik RB1100AHx4 Dude Edition
Артикул №: 1000146829
Категория:
Мрежови адаптери
368,99 €
✓ Налично във външен склад
MikroTik RB1100AHx4 Dude Edition
RB1100Dx4
New RB1100AHx4 Dude Edition has Annapurna Alpine AL21400 CPU with four Cortex A15 cores clocked at 1.4GHz each, for a maximum throughput of up to 7.5Gbps. The device supports IPsec hardware acceleration and is faster at it than any previous RouterBOARD device (up to 2.2Gbps with AES128).
Unit comes with 1U rackmount case, 13x Gigabit Ethernet ports, RS232 serial port and dual redundant power supplies (with -48v DC telecom power and 802.3at/af support). The RB1100AHx4 Dude edition features several high speed storage connectors (two SATA and two M.2) for using a Dude database, proxy cache or any other storage intensive feature. It includes a 60GB M.2 drive already installed.
Характеристики
| Product code RB1100Dx4 | Да |
| Architecture ARM | 32bit |
| CPU AL21400-1400-A0-E-1AN-8-C | Да |
| CPU core count | 4 |
| CPU nominal frequency | 1.4 GHz |
| Dimensions 444 x 148 | x 47 mm |
| License level | 6 |
| Operating System RouterOS | Да |
| Size of RAM | 1 GB |
| Storage size | 128 MB |
| Storage type NAND | Да |
| Powering | Да |
| Details | Да |
| Max Power consumption | 25W |
| Number of DC inputs | 2 (PoE-IN, 2-pin terminal) |
| PoE in | 802.3af/at |
| PoE in input Voltage | 20-57 V |
| 2-pin terminal input Voltage -48, 12-57 V | Да |
| Number of AC inputs | 2 |
| AC input range | 100-240 V |
| Ethernet | Да |
| Details | Да |
| 10/100/1000 Ethernet ports 13 | Да |
| Peripherals | Да |
| Details | Да |
| Extended storage | 60GB M.2 SSD included |
| M.2 slots | 2 |
| SATA ports | 2x SATA3 |
| Serial port RS232 | Да |
| Other | Да |
| Details | Да |
| Current Monitor | Да |
| PCB temperature monitor | Да |
| Voltage Monitor | Да |
