Legrand
Разклонител Legrand 6 945 04
Артикул №: 1000026092
Категория:
Разклонители
39,99 €
✓ Налично във външен склад
Legrand
3x 2P+E - to be wired
with 2 USB Type-A+C charging module
694504
Mechanical characteristics
Impact tests: IK 04
Protection against solid/bodies and liquids: IP 20
Material characteristics
Plastic + thermoplastiqc:
Matt White RAL 9003
Painted Aluminium
Halogen-free
UV-resistant
Self-extinguishing:
750°C/30 s for insulating components holding live parts in place.
650°C/30 s for other insulating components.
Electrical characteristics
2P+E outlets:
Voltage: 230 V~
Frequency: 50 Hz
Current: 16 A
Power: 3680 W max.
USB:
1 USB Type-A port + 1 USB Type-C port
3.0 A - 5.0 V - 15.0 W max.
Average active efficiency: 84.3%
Low-load efficiency (10%): 82.4%
Electricity consumption when not charging: 0.09 W
Climate characteristics
Usage temperature: -5°C to +35°C
Storage temperature: -20°C to +70°C
3 x 2P+E - Бяло/Алуминий
Без кабел
Оборудван с 2 USB Тип-A и USB Тип-C: 3.0 A -
5.0 V - 15 W MA
3x 2P+E - to be wired
with 2 USB Type-A+C charging module
694504
Mechanical characteristics
Impact tests: IK 04
Protection against solid/bodies and liquids: IP 20
Material characteristics
Plastic + thermoplastiqc:
Matt White RAL 9003
Painted Aluminium
Halogen-free
UV-resistant
Self-extinguishing:
750°C/30 s for insulating components holding live parts in place.
650°C/30 s for other insulating components.
Electrical characteristics
2P+E outlets:
Voltage: 230 V~
Frequency: 50 Hz
Current: 16 A
Power: 3680 W max.
USB:
1 USB Type-A port + 1 USB Type-C port
3.0 A - 5.0 V - 15.0 W max.
Average active efficiency: 84.3%
Low-load efficiency (10%): 82.4%
Electricity consumption when not charging: 0.09 W
Climate characteristics
Usage temperature: -5°C to +35°C
Storage temperature: -20°C to +70°C
3 x 2P+E - Бяло/Алуминий
Без кабел
Оборудван с 2 USB Тип-A и USB Тип-C: 3.0 A -
5.0 V - 15 W MA
Технически характеристики
| Impact tests | IK 04 |
| Напрежение | 230 V~ |
| Честота | 50 Hz |
| Ток | 16 A |
| Average active efficiency | 84.3% |
| Low-load efficiency (10%) | 82.4% |
| Usage temperature | -5°C to +35°C |
| Температура на съхранение | -20°C to +70°C |
