Публичен дисплей Sharp MultiSync E509
The entry point for professional display solutions, the Sharp MultiSync E9 Series is designed for modern business environments that need more than a consumer TV can offer. Combining essential features for meeting rooms and digital signage with commercial-grade reliability, the E9 Series delivers crisp UHD resolution, integrated media playback, and 16/7 operation at an accessible price point. A professional matte high-haze panel ensures superior visual performance in this product category, minimising reflections and glare common with glossy panels.
Designed for seamless integration across the wider Sharp display family, the E9 Series shares the same core identity, including the same remote control and device management for a consistent user experience. A robust metal back cover secures product longevity in commercial settings. Whether for presentations, retail signage, or corporate communication, the E9 Series gives you the professional edge without stretching your budget.
Характеристики
| Screen Size (inch)50 | Да |
| Screen Size (cm)127 | Да |
| Additional Features | Да |
| Colour VersionsBlack Back Cabinet, Black Front Bezel | Да |
| Свързаност | Да |
| DigitalHDMI, USB Type C | Да |
| Output ControlLAN | 100Mbit |
| Резолюция | Да |
| Optimum Resolution3840 x | 2160 at 60 Hz |
| Electrical | Да |
| Power Consumption on Mode [W]99 (shipping) | Да |
| Power Supply100-240 V, Internal Power Supply | Да |
| Environmental Conditions | Да |
| Operating Humidity (min) [%]20 | Да |
| Operating Humidity (max) [%]80 | Да |
| Mechanical | Да |
| Bezel Width (Left/Right) [mm]11 | Да |
| Bezel Width (Upper) [mm]11 | Да |
| Bezel Width (Lower) [mm]11 | Да |
| Green Features | Да |
| Ecological StandardsEnergy Star | 8.0 |
| Synchronisation Rate | Да |
| Horizontal Frequency [kHz]31.5 - | 135 |
| Vertical Frequency [Hz]24 - | 75 |
| Ergonomics | Да |
| Landscape Dimensions (Width) [mm]1120 | Да |
| Landscape Dimensions (Height) [mm]641 | Да |
| Landscape Dimensions (Depth) [mm]60 | Да |
| Panel Data | Да |
| Bezel Horizontal (mm)11 | Да |
| Bezel Vertical (mm)11 | Да |
| Panel Response Time (ms)8 | Да |
| PC-Input | Да |
| Input Data1 x USB | 2.0 (MediaPlayer) |
| Connectivity (Audio/Video) INPUT | Да |
| Аудио | 3.5mm Jack1 |
| Video Terminals | Да |
| Control TerminalsRS232C, LAN | Да |
| Audio Terminals | Да |
| Speaker Output (W RMS)Internal | 10W + 10W |
| Монтаж | Да |
| Portrait InstallationYes | Да |
| Landscape InstallationYes | Да |
| LandscapeYes | Да |
| PortraitYes | Да |
| Mounting (VESA mm)200 x | 200 (FDMI) |
| Mounting (Number of Points/Pitch)4 | Да |
| Mounting Screw Specification (Size/Max Length)M6 | Да |
| Display Module Data | Да |
| Panel TechnologyVA with Direct LED backlights | Да |
| Aspect Ratio16 | 9 |
| Brightness (cd/m²)350 | Да |
| Contrast Ratio4000 | 1 |
| Pixel Pitch (mm)0.285 | Да |
| Viewing Angle (°)178 | Да |
| Colour Depth [bn]1.07 (8bit + FRC) | Да |
| Active Screen Area (H/V) mm1095 x | 616 |
| Max. screen timeup to | 16 hours of use per day |
| Response Time (typ.) [ms]8 | Да |
| Key Specifications | Да |
| Built in Speakers (W)10 + | 10 |
| Remote ManagementYes | Да |
| Operating Time16/7 | Да |
| Touch Interface Specification | Да |
| Haze Level [%]Pro | 25 |
| Power Supply and Operating Environment | Да |
| Operating Voltage (ACV)100-240 | Да |
| Frequency (Hz)50-60 | Да |
| Via AC AdapterYes | Да |
| Operating Voltage (DCV)100-240 | Да |
| Operating Temperature (°C)0 - | 40 |
| Storage Temperature (°C)-20 - | 60 |
| Storage Humidity Min [%]10 | Да |
| Storage Humidity Max [%]80 | Да |
| Режим на пестене (W) | Да |
| Connectivity (Control/Serial) Data | Да |
| RS232C IN9600 | Да |
| RS232C OUT9600 | Да |
