PoE инжектор Ubiquiti UACC-PoE++-10G
Ubiquiti

PoE инжектор Ubiquiti UACC-PoE++-10G

Артикул №: 1000140979
Категория: Мрежови адаптери
47,99 €
✓ Налично във външен склад

The Ubiquiti UACC-PoE++-10G is a high-performance Power over Ethernet (PoE) injector designed to provide reliable power and data connectivity for your network devices. With an output voltage of 54V DC and a maximum power capacity of 60W per port, this device ensures efficient and robust power delivery, making it an ideal solution for devices requiring higher power such as IP cameras and access points. The Gigabit LAN port supports up to 10 GbE, allowing for fast data transmission that is crucial for today's bandwidth-intensive applications.

Crafted for durability and performance, the UACC-PoE++-10G features a compact design with dimensions of 106 x 63 x 34 mm and weighs just 210 g. It operates efficiently with an impressive efficiency rating of over 88%. This device also incorporates advanced surge protection for both data and power, ensuring the safety and longevity of connected equipment. Compliance with multiple certifications such as CE, FCC, IC, UL, UKCA, and more underscores its quality and reliability in various environments.

Designed for a wide range of applications, the Ubiquiti UACC-PoE++-10G operates within an ambient temperature range of 0 to 40° C and a storage temperature of -30 to 70°C. The capability to maintain performance under a humidity level of 10 to 95% non-condensing further enhances its versatility in real-world deployments. This PoE injector exemplifies Ubiquiti's commitment to innovation, providing essential functionality for today's demanding network solutions.

Характеристики

Weight210 g (7.4 oz) Да
Output Voltage54V DC @ 1.12A
LAN Activity IndicatorNo Да
Gigabit LAN PortYes, up to 10 GbE
Remote Reset CapabilityNo Да
Reset ButtonNo Да
Rated Voltage100—240V AC @ 50/60Hz
Input Current1.5A max Да
Inrush Current Да
Efficiency>88% Да
Output Ripple1% max Да
Switching Frequency65 kHz Да
Line Regulation≤ 2%
Load Regulation≤ 5%
2-Pair PoweringNo Да
4-Pair PoweringPins 1, 2, 4, 5 (+); 3, 6, 7, 8 (-) Да
Data In / PoERJ45 shielded socket Да
Surge ProtectionDifference and common mode Да
Clamping Protection11V data, 60V power
Max. Surge Discharge1500A (8/20 μs) power Да
Peak Pulse Current36A (10/1000 μs) data Да
Shunt Capacitance Да
Време за отговор Да
Max. PoE+ Wattage per Port by PSE60W Да
Ambient Operating Temperature0 to 40°C (32 to 104°F)
Storage Temperature-30 to 70°C (-22 to 158°F)
Ambient Operating Humidity10 to 95% noncondensing
CertificationsCE, FCC, IC, UL, UKCA, KC, CCC, RoHS Да
