Охлаждане за процесор Noctua NH-D9L chromax.black
Noctua NH-D9L
The NH-D9L chromax.black is is an all-black version of Noctua’s award-winning NH-D9L compact dual tower CPU cooler that has been designed to provide excellent quiet cooling performance at a height of only 110mm. Its comparably low profile (15mm lower than classic 9cm tower coolers such as the NH-U9S) doesn't only guarantee full 3U compliance but also makes the NH-D9L ideal for compact HTPC and Small Form Factor cases that have airflow paths parallel to the mainboard. Thanks to its 95x95mm footprint, the NH-D9L clears the RAM and PCIe slots on all Intel based and most AMD based ITX mainboards. The included NF-A9 premium fan supports automatic speed control via PWM for outstanding quietness of operation and a second, optional NF-A9 fan can be added for further improved performance in dual fan mode. Topped off with the trusted, pro-grade SecuFirm2™ multi-socket mounting system, Noctua’s proven NT-H1 thermal compound and full 6 years manufacturer’s warranty, the NH-D9L forms a highly compact premium package for space-restricted applications.
Cooler Specification:
Socket compatibility
Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 and AMD AM5, AM4
Height (without fan)
Характеристики
| Материал | Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating |
| NSPR | 88 |
| Fan compatibility | 92x92x25 |
| FAN Specification | Модел |
| Noctua NF-A9 PWM chromax.black | Bearing |
| SSO2 | Max. rotational speed (+/- 10%) |
| 2000 RPM | Max. rotational speed with L.N.A. (+/- 10%) |
| 1550 RPM | Min. rotational speed @ 20% PWM (+/-20%) |
| 400 RPM | Max. airflow |
| 78,9 m³/h | Max. airflow with L.N.A. |
| 62,6 m³/h | Max. acoustical noise |
| 22,8 dB(A) | Max. acoustical noise with L.N.A. |
| 16,3 dB(A) | Airflow |
| 78.9 m³/h | Airflow with L.N.A. |
| 62.6 m³/h | Acoustical noise |
| 22.8 dB(A) | Input power (max.) |
| 1,2 W | Voltage range |
| 12 V | MTTF |
