Dahua
Монитор Dahua VTH5221DW
Артикул №: 1000013938
Категория:
Монитори за Видеонаблюдение
143,99 €
✓ Налично във външен склад
Features
· 7" TFT Capacitive touch screen, 1024x600
· IPC surveillance
· 6ch wired alarm integration, 6ch wireless alarm
integration(433MHZ)
· Micro SD card optional, max 32GB
· Record & Snapshot(SD card needed)
Technical Specification
Model: VTH5221D/DW-C
System
Main Processor: Embedded Micro Processor
Operation System: Embedded LINUX OS
Video
Video Compression: H.264
Image Sensor: 1/4” 1MP CMOS
Lens: 2.2mm
Angle of View: D:125° H:105°
Audio
Audio Compression: G.711
Audio Input: All-direction Microphone
Audio Output: Built-in Loudspeaker
Bidirectional: Talk Support Dual-way Bidirectional talk
Display
LCD Screen: 7“ 1024x600, Capacitive
Operation Mode
Input: Touch buttons
Interface
Wired Zones: 6 on-board zones
Wireless Zones: 6 wireless zones
Alarm Out: 1
RS485: 1
Network
Wi-Fi: IEEE802.11b/g/n
Ethernet: 10M/100Mbps Self-adaptive
Network Protocol: TCP/IP
General
Memory Slot: Micro SD, Max 32GB
Installation: Surface
Power DC: 12V, PoE（802.3af)
Power Consumption: Standby ≤1W, Work ≤7W
Working Temperature: ﹣10°C~+55°C
Relative Humidity: 10%~90%RH
Dimensions: 215.0mm×140.0mm×21.0mm
Weight: 0.8Kg
· 7" TFT Capacitive touch screen, 1024x600
· IPC surveillance
· 6ch wired alarm integration, 6ch wireless alarm
integration(433MHZ)
· Micro SD card optional, max 32GB
· Record & Snapshot(SD card needed)
Technical Specification
Model: VTH5221D/DW-C
System
Main Processor: Embedded Micro Processor
Operation System: Embedded LINUX OS
Video
Video Compression: H.264
Image Sensor: 1/4” 1MP CMOS
Lens: 2.2mm
Angle of View: D:125° H:105°
Audio
Audio Compression: G.711
Audio Input: All-direction Microphone
Audio Output: Built-in Loudspeaker
Bidirectional: Talk Support Dual-way Bidirectional talk
Display
LCD Screen: 7“ 1024x600, Capacitive
Operation Mode
Input: Touch buttons
Interface
Wired Zones: 6 on-board zones
Wireless Zones: 6 wireless zones
Alarm Out: 1
RS485: 1
Network
Wi-Fi: IEEE802.11b/g/n
Ethernet: 10M/100Mbps Self-adaptive
Network Protocol: TCP/IP
General
Memory Slot: Micro SD, Max 32GB
Installation: Surface
Power DC: 12V, PoE（802.3af)
Power Consumption: Standby ≤1W, Work ≤7W
Working Temperature: ﹣10°C~+55°C
Relative Humidity: 10%~90%RH
Dimensions: 215.0mm×140.0mm×21.0mm
Weight: 0.8Kg
Технически характеристики
| Модел | VTH5221D/DW-C |
| Main Processor | Embedded Micro Processor |
| Operation System | Embedded LINUX OS |
| Video Compression | H.264 |
| Image Sensor | 1/4” 1MP CMOS |
| Lens | 2.2mm |
| Angle of View | D:125° H:105° |
| Audio Compression | G.711 |
| Audio Input | All-direction Microphone |
| Audio Output | Built-in Loudspeaker |
| Bidirectional | Talk Support Dual-way Bidirectional talk |
| LCD Screen | 7“ 1024x600, Capacitive |
| Input | Touch buttons |
| Wired Zones | 6 on-board zones |
| Wireless Zones | 6 wireless zones |
| Alarm Out | 1 |
| RS485 | 1 |
| Wi-Fi | IEEE802.11b/g/n |
| Ethernet | 10M/100Mbps Self-adaptive |
| Network Protocol | TCP/IP |
| Memory Slot | Micro SD, Max 32GB |
| Монтаж | Surface |
| Power DC | 12V, PoE（802.3af) |
| Консумация на енергия | Standby ≤1W, Work ≤7W |
| Working Temperature | ﹣10°C~+55°C |
| Relative Humidity | 10%~90%RH |
| Размери | 215.0mm×140.0mm×21.0mm |
| Тегло | 0.8Kg |
