LED прожектор Ledvance

Product benefits

• Robust, yet light and compact design
• Demand optimized illumination due to flexible and programmable sensor
• Easy adjustment of sensor range, daylight detection and hold time
• Always-on override, activated via special mains switching pattern
• Safe and very uniform illumination, due to frosted and tempered glass diffuser
• No upper light output ratio (ULOR 0%) when mounted at 0° tilt
• Energy savings of up to 90 % compared to halogen lamp floodlights

Areas of application

• Replacement for floodlights with halogen lamps
• Outdoor use (IP65)
• Public areas
• Building facades
• Gardens, balconies and other outdoor areas
• Construction areas

Product features

• Flexible motion and daylight sensor
• Sensor with 350° pan and 180° tilt
• Reflector-based, symmetric light distribution with 100° x 100° beam angle
• Mounting bracket with 30° angle and wide rotation area
• Pre-installed, flexible 1 m cable (H05RN-F), wrapped 3 x 1.0 mm² single wires

Technical data

Electrical data

Nominal wattage 50.00 W

Nominal voltage 220…240 V

Mains frequency 50…60 Hz

Nominal current 245 mA

Inrush current 5.2 A

Inrush current time Th50 1 µs

Max. number of luminaires per miniature circuit breaker B16 36

Max. number of luminaires per miniature circuit breaker C10 26

Max. number of luminaires per miniature circuit breaker C16 42

Power factor λ > 0.90
