Ledvance
LED луна за вграждане Ledvance DL SLIM DN 105 WT
Артикул №: 1000141547
Категория:
Електрически крушки
14,99 €
✓ Налично във външен склад
Product benefits
- Very slim housing
- Low installation depth
- High luminous efficacy
- Energy savings up to 60 % (compared to luminaires that use CFL lamps)
- Very homogenous light
- Functional design
- Easy installation with fast connection
- Simple installation thanks to integrated driver
Areas of application
- Direct replacement for luminaires with compact fluorescent lamps
- General illumination
- Public areas
- Stairways
- Corridors
- Foyers
- Shops
Product features
- Small visible bezel
- Connector box with push wire terminal for tool-free connection
- Light guide made of non-yellowing PMMA for long lifetime
Safety advice
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
- The luminaires are not suitable for covering with thermally insulated material.
Technical data
Electrical data
Nominal wattage6.00 W
Nominal voltage220…240 V
Mains frequency50…60 Hz
Nominal current58 mA
Inrush current6 A
Inrush current time Th50120 µs
Max. number of luminaires per miniature circuit breaker B1672
Max. number of luminaires per miniature circuit breaker C1060
Max. number of luminaires per miniature circuit breaker C1696
Power factor λ0.50
Характеристики
| Total harmonic distortion | Photometrical data |
| Luminous flux420 lm | Luminous efficacy70 lm/W |
| Color temperature3000 K | Light color (designation)Warm White |
| Color rendering index Ra> 80 | Standard deviation of color matching |
| Dimensions & Weight | Diameter118.00 mm |
| Height30.00 mm | Product weight158.00 g |
| Materials & Colors | Product colorWhite |
| Housing colorWhite | Body materialPolycarbonate (PC) |
| Cover materialPolycarbonate (PC) | Light emitting surface materialPolycarbonate (PC) |
