Кутия Thermaltake View 380 XL TG ARGB Snow
Thermaltake View 380 XL TG ARGB Snow
The View 380 XL TG ARGB Snow was designed with both performance and of course stunning views in mind. Sporting a fish tank dual chamber design, angled side intake with a curved mesh, recessed bottom fan mounts, and hinged storage doors in the rear compartment. On top of that there is room for radiators up to 360mm in length, GPUs up to 420mm in length and enough space to accommodate up to ten 120mm fans.
Hidden Connectors, Hidden Cables
Whether building with a standard layout motherboard or a brand-new hidden connector board the View 380 XL TG ARGB Snow has you covered. Featuring cutouts that support the installation and routing for standard motherboards and hidden connector boards from companies like ASUS, MSI, and GIGABYTE. No matter what you choose the View 380 XL TG ARGB Snow is the perfect candidate for a clean looking build.
Dual Chamber
Dual chamber chassis generally have the benefits of an increase in cable management and back section space and the View 380 XL TG ARGB Snow is no exception. Utilizing a floating style PSU mount the rear chamber has ample room and tie downs for routing and managing cables for a easy to work with layout.
Характеристики
| Модел | View 380 XL TG ARGB |
| Серия | View |
| Размери | 471 x 288 x 469 mm · (18.54 x 11.34 x 18.46 inch) |
| Side Panel | 4mm Tempered Glass x 2 |
| Цвят | Snow |
| Материал | SPCC |
| Cooling System | Right(intake): 120 x 120 x 25 mm ARGB Lite Reverse fan (1000rpm, 21.9 dBA) x 3 · Rear(exhaust): 120 x 120 x 25 mm ARGB Lite fan (1000rpm, 22.3 dBA) x 1 |
| Drive Bays | 1 x 3.5”, 2 x 2.5” or 3 x 2.5” |
| Слотове за разширение | 8 |
| Motherboard | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) |
| I/O Port | USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1 |
| PSU | Standard PS2 PSU (optional) |
| Fan Support | Top: · 3 x 120mm, 2 x 120mm, 1 x 120mm, · 2 x 140mm, 1 x 140mm · · Right: · 3 x 120mm, 2 x 120mm, 1 x 120mm · · Rear: · 1 x 120mm · · Bottom: · 3 x 120mm, 2 x 120mm, 1 x 120mm |
| Radiator Support | Top: · 1 x 360mm, 1 x 240mm, 1 x 120mm · 1 x 280mm, 1 x 140mm · · Right: · 1 x 360mm, 1 x 240mm, 1 x 120mm · · Rear: · 1 x 120mm |
| Clearance | CPU cooler max height: 160mm · VGA max length: 420mm · PSU max length: 180mm |
