Кутия MSI MAG PANO 130R PZ
MSI

Кутия MSI MAG PANO 130R PZ

Артикул №: 1000149039
Категория: Компютърни компоненти
92,99 €
✓ Налично във външен склад

MSI MAG PANO 130R PZ

Panoramic DisplayTo fulfill the desire for showcasing an ARGB PC build, the MAG PANO 130R Series features a 270-degree panoramic display, enhancing aesthetics and maintaining a clean design.

Airflow optimization

Vents around the case

Increase the number of vents on the sides and front of the case to enhance overall heat dissipation.

Cooling support

Toolless removable glass panelsScrewless mounting and tool-free removable panel design on both sides allow for greater setup flexibility.

Dust protectionA magnetic dust filter is installed on the bottom of the case, while a removable filter covers the bottom vents - both designed to prevent dust buildup and allow for easy cleaning.

Support ATX and MicroATX back-connect motherboard (PZ series)

Enable a clean layout by routing cables through the rear, simplifying installation and enhancing the aesthetic appeal of any gaming setup.

Rotatable GPU BracketOne bracket, two orientations. A quick 90° rotation allows quick switching between horizontal and vertical GPU installations.(Riser cable sold separately)Built with a unified aesthetic in mind, the design features bold diagonal lines and sharp cut angles—perfectly matching MAG series motherboards, liquid coolers, and power supplies. It brings a cohesive, polished look to your entire PC build.

Характеристики

Mid-Tower Да
Motherboard Form Factor Support Да
Regular ATX / Micro-ATX / Mini-ITX
Back-connect ATX / Micro-ATX
I/O Ports
2 x USB 5Gbps (Type-A)
1 x USB 20Gbps (Type-C)
1 x Audio-Out / Mic-in
1 x Reset Button
1 x Power Button
Drive Mount Support
Up to 3 x 2.5” SSD
Up to 2 x 3.5” HDD
(Maximum of 3 drives can be mounted at once, depending on configuration)
Expansion Slots
7
Maximum GPU Length
400 mm / 15.75 inches
Maximum CPU Cooler Height
165 mm / 6.50 inches
Power Supply Support
ATX
Maximum PSU Length
180 mm / 7.09 inches
Fan Size Support
Top: 3 x 120 mm / 2 x 140 mm
Front: N/A
Rear: 1 x 120 mm
Side: 3 x 120 mm
Bottom: 3 x 120 mm (Above the power shroud)
Pre-installed Fan Type
Rear: 1 x 120 mm ARGB Fan
Side: 3 x 120 mm ARGB Fan (Reverse Blade Fan)
Radiator Size Support
Top: 120 / 140 / 240 / 280 / 360 mm
Front: N/A
Rear: 120 mm
Side: 120 / 240 / 360 mm
Bottom: N/A
Dimensions (DxWxH) & Weight
460 x 232 x 490 mm / 18.11 x 9.25 x 19.29 inches
Net Weight: 8.37 kg / 18.45 lbs
