IP видеорекордер Dahua VIGI NVR1108H-W
Артикул №: 1000037577
Категория:
NVR Записващи устройства
250,99 €
✓ Налично във външен склад
Dahua VIGI NVR1108H-W
- 8-Channel Live View and 4K HDMI Video Output
- Built-in Routering Module and Support Wireless Pairing*
- Up to 8-ch @ 2MP (25fps) / 4-ch @ 4MP (25fps) Decoding Capability
- 8-Channel Synchronous Playback†
Video and Audio
| IP Video Input | 8-Channel |
| Incoming Bandwidth | 80 Mbps |
| Outgoing Bandwidth | 60 Mbps |
| HDMI Output Resolution | 1 Channel, Resolution: 3840 ×2160/30Hz, 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| Video Output Mode | HDMI/VGA Simultaneous Output |
| Multi-View Display | 1/4/6/8 |
DECODING
| Audio Compression | G.711A/G.711U/G.726 |
| Video Compression | H.265+/H.265/ H.264+/H.264 |
| Record Resolution | 8 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Synchronous Playback | 8-Channel |
| Capability | • 25fps: · 2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP · · • 30fps: · 4-ch @ 3MP, 2-ch @ 5MP |
Record Management
| Record Mode | • Manual Recording · • Scheduling Recording · • Motion Detection Recording |
| Playback Mode | • Instant Playback · • Regular Playback · • Tag Playback · • Event Playback |
| Backup Mode | • Regular Backup · • Video Clip Backup |
| Playback Function | • Play · • Pause · • Stop · • Fast Forward · • Fast Backward · • Play By Frame · • Video Clip · • Export Clip · • Lock Recording · • Audio On/Off |
МРЕЖА
| Protocol | UPnP (Plug and Play), NTP (Network Timing), SMTP, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP |
| Mobile Phone Access | Android, iOS |
| Web Browser | Chrome (57+), Firefox (52+), Edge (91+) |
| Interoperability | ONVIF Profile S/T/G, CGI |
БЕЗЖИЧНИ ХАРАКТЕРИСТИКИ
| Standards and Protocols | IEEE 802.11b/g/n |
| WiFi Channels | • UN: 1-13 · • US: 1-11 |
| Wireless Name | • SSID Configuration · • Radio |
| Network Switch | Да |
| Честота | 2.4 GHz |
| Radio Bandwidth | • Auto: Yes · • 20M: Yes · • 40M: Yes |
| Wireless Rate | 300Mbps(802.11n), 2 × 2 MIMO |
| Wireless Security | WPA-PSK/WPA2-PSK |
External Interface
| Network Interface | • 1× RJ-45 10/100 Mbps Self-Adaptive WAN/LAN Ethernet Interface · • 1× RJ-45 10/100 Mbps Self-Adaptive LAN Ethernet Interface |
| USB Interface | 2× USB 2.0 |
| Audio Interface | 1-ch RCA Input; 1-ch RCA Output |
| Мощност | 1× DC Jack |
| Reset Button | 1 |
| Високоговорител | 1; Real-time Audio Output without Needing Peripherals |
| HDMI | 1 |
| VGA | 1 |
HARD DISK
| SATA | 1 SATA Interface |
| Капацитет | Up to 10 TB Capacity for Each HDD** |
Alarm
| General Alarm | • Motion Detection · • Video Tampering · • Scene Change Detection · • Line-Crossing Detection · • Intrusion Detection · • Region Entering Detection · • Region Exiting Detection · • Loitering Detection · • Object Abandoned/Removal Detection · • Vehicle Detection · • Human Detection · • Abnormal Sound Detection · • Smart Frame · Note: The alarm function requires the use of a camera |
| Anomaly Alarm | • Video Loss · • Offline and IP Conflict · • Disk Exception · • Login Exception · Note: The alarm function requires the use of a camera |
| Alarm Linkage | • Recording · • White Light Alarm · • Log · • Audible Alarm · Note: The alarm function requires the use of a camera |
ОБЩИ ХАРАКТЕРИСТИКИ
| Температура на съхранение | -40–70 °C |
| Storage Humidity | 10%~90% RH Non-Condensing |
| Съдържание на пакета | • VIGI Network Video Recorder · • Power Adapter · • HDD Screws · • Mouse · • Quick Installation Guide |
| Working Temperature | • NVR: -10–55 °C · • Power Adapter: 0–40 °C |
| Working Humidity | 10%~90% RH Non-Condensing |
| Размери (Ш x Д x В ) | Excluding Antennas: 7.9 × 7.9 × 1.7 in (200.3 × 200.3 × 43 mm) |
| Външно захранване | DC 12V/2A |
| Нето тегло | 0.5 kg |
| Бруто тегло | 1.0 kg |
| Max. Power Consumption | • 5.7 W (Without Disk) · • 16.3 W (Without Disk) |
| Antenna | • Quantity: 2 · • Type: 2.4GHz Welded Non-detachable Antenna · • Gain: 5.3dBi · • Radio Frequency Transmit Power: 16dBm · • Length: 198.8 mm for Long Side and 189 mm for Short Side |
