IP видеорекордер Dahua NVR2108HS-8P-4KS2
Dahua NVR2108HS-8P-4KS2
8 Channel Compact 1U 8PoE Lite 4K H.265 Network Video Recorder
H.265/H.264 codec decoding
Max 80Mbps incoming bandwidth
Up to 8Mp resolution preview&playback
Up to 1ch@8MP/4ch@1080P decoding
HDMI/VGA simultaneous video output
Support IPC UPnP, 8PoE ports
System
Main Processor
Dual-core embedded processor
Operating System
Embedded LINUX
Audio and Video
IP Camera Input
8 Channel
Two-way Talk
1 Channel Input, 1 Channel Output, RCA
Display
Interface
1 HDMI, 1 VGA
Resolution
HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720
VGA: 1920×1080, 1280×1024, 1280×720
Decoding Capacity
1ch@8MP 30fps, 4ch@1080P 30fps
Multi-screen Display
1/4/8/9
OSD
Camera title, Time, Camera lock, Motion detection, Recording
Recording
Compression
H.265/H.264
Resolution
8MP/6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc.
Record Rate
80Mbps
Bit Rate
16Kbps ~ 20Mbps Per Channel
Record Mode
Manual, Schedule(Regular(Continuous), MD, Stop
Record Interval
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection and Alarm
Trigger Events
Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips
Video Detection
Motion Detection, MD Zones: 396 (22 × 18),
and Tampering
Alarm input
N/A
Характеристики
| Relay Output | — |
| Playback and Backup | Sync Playback |
| 1/4 | Search Mode |
| Time /Date, MD and Exact Search | (accurate to second) |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode | USB Device/Network |
| Third-party Support | Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more |
| Network | Интерфейс |
| 1 RJ-45 port (10/100/1000Mbps) | PoE |
| 8 ports (IEEE802.3at/af) | Network Function |
