IP камера Compro IP570P
PTZ камера за видеонаблюдение, 12x оптично увеличение, 1.3 Mpix резолюция, подходяща за дневно и нощно наблюдение, PoE захранване.
1/4" progressive scan CMOS vivid image матрица
1.3 Megapixels 1280x1024 HD sharp резолюция
H.264, MPEG-4, M-JPEG компресия, поддържа dual streaming
Пълна поддръжка на звук, вграден микрофон, аудио вход и изход; two-way audio communication поддръжка
True Day & Night illumination с ICR-контролирани IR LEDs, дистанция до 15 м
Поддържа до 30 preset траектории за наблюдение
ComproView 32-канална охранителна система
Digital I/O 3-in/3-out, позволява свързване с външни сензори и аларми
Анализ на събития, детекция на движение и звук
IEEE 802.11b/g/n WiFi съвместима (опция)
microSD/SDHC порт за локален запис; до 32GB (не включва карта)
3GPP или M-JPEG мобилен достъпподдържа Andriod, BlackBerry, iPhone, Windows Mobile
WebVUer отдалечено наблюдение, multi-channel разположение на екрана, поддържа до 16 канала
12x оптично увеличение, автом. фокус и ирис контрол
Introduction
Compro IP570P camera offers Power Over Ethernet and an advance 12x auto-focus optical zoom with 340-degree panning and 100-degree tilting mechanical design for continuous movement, ideal for live monitoring locations need to follow a person or objects such as home, warehouse, small business or restaurant lobby area.
Key Features
Pan/Tilt with 12x auto-focus optical zoom
Power Over Ethernet design, no power adaptor required
Day & Night function, operates under all light condition
Built-in IR cut filter and IR LEDs
H.264, MJPEG or MPEG-4 triple codec with dual streams support
Megapixel / 1280x1024 HD resolution
Built-in microphone
Two-way audio
Local MicroSD/SDHC card storage for recordings or snap shots
Bundled 3-input/3-output external I/O expansion box with built-in RF receiver
Support live video watch in FireFox, Safari, Google Chrome web browsers. (with VLC Plug-in installed)
Exclusive Multiple Channels Management in IE
Exclusive mobile device PTZ control
Upgradeable Wifi USB module to 802.11 b/g/n wireless LAN
Easy and smart installation
Mobile connectivity
Характеристики
| Image Sensor | 1/4" CMOS Megapixel sensor |
| Lens • Focal Length | 3.8(Wide) ~ 45.6(Tele) mm |
| Max Aperture Ratio | F1.65(Wide) ~ F360(Tele) |
| Auto iris | Да |
| Angle of View | 52.8° (Wide), 4.49° (Tele) |
| Focusing Range | 1m ~ INF |
| Pan Range -170° ~ +170° total of | 340 degree |
| Tilt Range -10° ~ +90° total of | 100 degree |
| Max Speed Pan | 45°/Sec., Tilt 35°/Sec |
| Zoom | 12x optical zoom |
| Min Illumination • IR Mode | 0 lux; using built-in IR light in darkness up to 10m |
| Color Mode | 1.0 lux |
| Shutter Time | 1/5 ~ 1/16000 sec |
| Video | Да |
| Video Compression | Да |
| H.264 ( MPEG-4 Part | 10) |
| Motion JPEG | Да |
| MPEG-4 Part | 2 |
| Resolutions | 160x120, 320 x 240, 640 x 480, 1280 x 1024 |
| Frame Rate • Up to | 30 frames at 640 x 480 |
| до | 15 frames at 1280 x 1024 |
| Video Streaming Dual H.264, MJPEG or MPEG-4 video streams | Да |
| Image Setting • Adjustable image size and quality | Да |
| AGC, AWB, AES | Да |
| Аудио | Да |
| Audio Compression G.711 PCM | 64Kbit/sec |
| Audio Input / Output MIC input / Audio out | Да |
| Networking | Да |
| Security User ID / Password Protection | Да |
| Firmware | Да |
| Firmware • Support UPnP | Да |
| Support online firmware update | Да |
| Софтуер | Да |
| ComproView • Multiple channel management | Да |
| iDDNS service for dynamic IP and desktop shortcut creation | Да |
| Recording search and playback | Да |
| Scheduled and event driven management | Да |
| Smart Detection | Да |
| Web Browser | Да |
| Capture a still image and save it in JPG format on PC | Да |
| Alarm and event management | FTP, I/O alarm, server notification and email |
| Support Devices | Да |
| PC, Laptop, Nettop, MID with IE/ActiveX support | Да |
| Mobile phone, iphone/ipod, PDA support in MJPEG mode | Да |
| Mobile Phone | Да |
| MJEPG Mode Viewing of camera image via phone browsers | Да |
| General | Да |
| Operating conditions | 5 °C ~ 40 °C |
| Power Supply PoE (IEEE | 802.3af PoE Class 3), DC 12V/2A |
| System Requirements | Да |
| Computer with | 1.7GHz processor and 512 MB memory or above |
| Supported Operating Systems | Windows XP SP3, Vista SP1, Windows 7 |
| PoE switch with | 802.3af PoE Class 3 support |
| PoE connection needs Cat.5 network cable | Да |
| Размери | 105 x 125.5 x 128.6 mm |
| http | //www.comprousa.com/en/product/ip570p/ip570p-specifications.html |
