Gigabyte
Дънна платка Gigabyte B760M H V2
Артикул №: 1000043784
Категория:
Дънни платки за Intel процесори
99,99 €
✓ Налично във външен склад
- CPU
- LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU - Chipset
- Intel® B760 Express Chipset
- Memory
- Support for DDR5 8000(O.C.) /7800(O.C.) /7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules
2 x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity) of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.) - Onboard Graphics
Integrated Graphics Processor-Intel® HD Graphics support:
- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.2 version and HDCP 2.3
Технически характеристики
| Процесор сокет | LGA 1700 |
| Чипсет | B760 |
| Поддържана памет | DDR5 |
| Брой слотове за RAM памет | 2 |
| Storage интерфейси | SATA 6Gbit/s, M.2 |
| RAID | Да |
| Безжични мрежи | Не |
| Bluetooth | Не |
| Видео слот | PCI-E |
| Видео изход | DP HDMI |
| Форм фактор | Micro ATX |
