Gigabyte
Дънна платка Gigabyte B550M K
Артикул №: 1000127433
Категория:
Компютърни компоненти
90,99 €
✓ Налично във външен склад
Характеристики
| AMD Ryzen™ | 5000 Series |
| AMD Ryzen™ | 5000 G-Series |
| AMD Ryzen™ | 4000 G-Series |
| AMD Ryzen™ | 3000 Series |
| Сокет | Да |
| AMD Socket AM4 | Да |
| Чипсет | Да |
| AMD B550 | Да |
| Памет | Да |
| Dual channel memory architecture | Да |
| Support for ECC Un-buffered DIMM | 1Rx8/2Rx8 memory modules* |
| ECC memory (ECC mode) support varies by CPU | Да |
| Support for Extreme Memory Profile (XMP) memory modules | Да |
| Onboard Graphics | Да |
| Integrated Graphics Processor | 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz * Support for DisplayPort 1.4 version, HDCP 2.3, and HDR. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version, HDCP 2.3, and HDR. Maximum shared memory of 16 GB Audio Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. LAN Realtek® GbE LAN chip (1 Gbps/100 Mbps) Expansion Slots |
| 1 x PCI Express x16 slot, integrated in the CPU | AMD Ryzen™ 5000 Series/3000 Series Processors support PCIe 4.0 x16 mode AMD Ryzen™ 5000 G-Series/4000 G-Series Processors support PCIe 3.0 x16 mode |
| 1 x PCI Express x1 slot, integrated in the Chipset | Supporting PCIe 3.0 x1 mode Storage Interface |
| 4 x SATA 6Gb/s connectors, integrated in the Chipset | Support for RAID 0, RAID 1, and RAID 10 USB |
| Процесор | 4 x USB 3.2 Gen 1 ports on the back panel |
| Чипсет | 2 x USB 3.2 Gen 1 ports available through the internal USB header 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x DisplayPort 1 x HDMI port 4 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks I/O Controller iTE® I/O Controller Chip BIOS 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 Operating System Support for Windows 11 64-bit Support for Windows 10 64-bit Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm |
