Ubiquiti
Антена Ubiquiti LiteBeam M5 (LBE-M5-23)
Артикул №: 1000027406
Категория:
Безжични мрежи аксесоари
55,99 €
✓ Налично във външен склад
Ubiquiti LiteBeam M5 (LBE-M5-23)
Physical / Electrical / Environmental
Dimensions (No Mount)
362 x 267 x 184 mm
Weight (No Mount)
750 g
Mounting Kit
Pole Mounting Kit (Included)
Max. Power Consumption
4W
Power Supply
24V, 0.2A PoE Adapter (Included)
Power Method
Passive PoE (Pairs 4, 5+; 7, 8 Return)
Operating Temperature
-40 to 70° C (-40 to 158° F)
Operating Humidity
5 to 95% Noncondensing
Shock and Vibration
ETSI300-019-1.4
ETSI Specification
EN 302 326 DN2
ESD/EMP Protection
± 24 KV Contact / Air
System Information
Processor Specs
MIPS 74K
Memory
64 MB
Networking Interface
(1) 10/100 Ethernet Port
Regulatory / Compliance Information
Wireless Approvals
FCC, IC, CE
RoHS Compliance
Yes
Antenna Information
Operating Frequency
Worldwide: 5150 - 5875 MHz
Output Power
25 dBm
Gain
23 dBi
Max. VSWR
1.5:1
12 месеца за юридически, 24 месеца за физически лица
Physical / Electrical / Environmental
Dimensions (No Mount)
362 x 267 x 184 mm
Weight (No Mount)
750 g
Mounting Kit
Pole Mounting Kit (Included)
Max. Power Consumption
4W
Power Supply
24V, 0.2A PoE Adapter (Included)
Power Method
Passive PoE (Pairs 4, 5+; 7, 8 Return)
Operating Temperature
-40 to 70° C (-40 to 158° F)
Operating Humidity
5 to 95% Noncondensing
Shock and Vibration
ETSI300-019-1.4
ETSI Specification
EN 302 326 DN2
ESD/EMP Protection
± 24 KV Contact / Air
System Information
Processor Specs
MIPS 74K
Memory
64 MB
Networking Interface
(1) 10/100 Ethernet Port
Regulatory / Compliance Information
Wireless Approvals
FCC, IC, CE
RoHS Compliance
Yes
Antenna Information
Operating Frequency
Worldwide: 5150 - 5875 MHz
Output Power
25 dBm
Gain
23 dBi
Max. VSWR
1.5:1
12 месеца за юридически, 24 месеца за физически лица
Характеристики
| Ubiquiti LiteBeam M5 (LBE-M5-23) | Physical / Electrical / Environmental |
| Dimensions (No Mount) | 362 x 267 x 184 mm |
| Weight (No Mount) | 750 g |
| Mounting Kit | Pole Mounting Kit (Included) |
| Max. Power Consumption | 4W |
| Захранване | 24V, 0.2A PoE Adapter (Included) |
| Power Method | Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Работна температура | -40 to 70° C (-40 to 158° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Shock and Vibration | ETSI300-019-1.4 |
| ETSI Specification | EN 302 326 DN2 |
| ESD/EMP Protection | ± 24 KV Contact / Air |
| System Information | Processor Specs |
| MIPS 74K | Памет |
| 64 MB | Networking Interface |
| 1) 10/100 Ethernet Port | Regulatory / Compliance Information |
| Wireless Approvals | FCC, IC, CE |
| RoHS Compliance | Да |
| Antenna Information | Operating Frequency |
